Envo SC-150-12 Power Supply 150W 12V - Triac dimmable 12.5A
Please Login for Pricing
Description
Description
- Output constant voltage
- Universal AC input/ :180-240VA
- High efficiency :up to 87%
- Protections:short circuit/over loading/over current
- Full protection aluminum housing
- Easy installation
- Cooling by free air convection
- Work with leading edge and trailing edge TRIAC dimmers
- Strong compatibility
- flicker-free dimming
- Suitable for LED lighting and moving sign applications
- Compliance to worldwide safety regulations for lighting
Specifications
Specifications
-
BrandEnvo
-
SeriesSC Envo Series
-
Power Rating150 Watt
-
Output Voltage12 Volt
-
Rated Current12.5 Ampere
-
Input Voltage180V~240V
-
Standards MetCE,SAA
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~60°C
-
Warranty5 Year
-
Length25.6 cm
-
Width7.8 cm
-
Height4.7 cm
-
Weight1.5 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What type of output does the Envo SC-150-12 provide?
The Envo SC-150-12 is a constant-voltage power supply with a 12V DC output. It is designed for applications that require stable 12V power rather than constant-current control. This makes it suitable for compatible 12V LED lighting and moving sign applications.
Is the Envo SC-150-12 dimmable?
Yes, this model supports AC phase-cut dimming and is described as Triac dimmable. It works with both leading-edge and trailing-edge TRIAC dimmers. The product description also states strong compatibility and flicker-free dimming performance.
What is the power and current rating of this model?
This power supply is rated for 150W output power at 12V. Its rated output current is 12.5A. These specs make it a higher-capacity option for 12V constant-voltage lighting loads.
What kinds of applications is the SC-150-12 intended for?
The product description lists LED lighting and moving sign applications as suitable uses for this model. Its constant-voltage 12V output and TRIAC dimming support make it relevant for commercial and project-based lighting setups. Buyers looking for a dimmable 12V LED power supply may find it appropriate for those environments.
Can this power supply operate in demanding temperature conditions?
Yes, the specified operating temperature range is -40°C to 60°C. That wide range can be useful in environments where ambient conditions vary significantly. Buyers should still confirm the overall application environment matches the product's rated limits.
What protection features are included in the Envo SC-150-12?
According to the product data, this model includes protections for short circuit, over loading, and over current. It also uses a full-protection aluminum housing. These features are intended to support durability and dependable operation in lighting applications.
How does the SC-150-12 compare with non-dimmable 12V power supplies?
A key differentiator of the SC-150-12 is its AC phase-cut dimming support, including compatibility with leading-edge and trailing-edge TRIAC dimmers. Non-dimmable 12V power supplies do not offer that same dimming functionality. This model is better suited when smooth, flicker-free dimming is a project requirement.
Other SC-150 Models
1 other model| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Envo SC-150-24 Power Supply 150W 24V - Triac dimmable 6.25A | 150W | 24V | 6.25A | IP66 | View |
