Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Envo SC-30-24-US Power Supply 30W 12V - Triac dimmable 1.25A
Log in to see price- Output constant voltage
- Range AC input/ :180-240VAC
- Built-in active PFC function
- Efficiency :up to 85%
- Protections:short circuit/over loading/over current
- Full protection plastic housing easy installation
- IP20 design for indoor installation
- Cooling by free air convection
- Work with leading edge and trailing edge TRIAC dimmers
- Strong compatibility
- flicker-free dimming
- Suitable for LED lighting and moving sign applications
- Suitable for dry locations
-
BrandEnvo
-
SeriesSC Envo Series
-
Power Rating30 Watt
-
Output Voltage24 Volt
-
Rated Current1.25 Ampere
-
Input Voltage100V~130V
-
Standards MetCE,SAA,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~60°C
-
Warranty5 Year
-
Length18 cm
-
Width6 cm
-
Height3.5 cm
-
Weight0.55 kg
::specification::
Frequently Asked Questions
What are the electrical output ratings of the Envo SC-30-24-US?
This model is a 30W constant-voltage power supply with a rated 24V DC output. Its rated output current is 1.25A. It is intended for applications that require a 24V constant-voltage LED power source.
Is the SC-30-24-US compatible with TRIAC dimming systems?
Yes. The SC-30-24-US is designed to work with both leading-edge and trailing-edge TRIAC dimmers. The product description also notes strong compatibility and flicker-free dimming performance for supported LED lighting applications.
What types of applications is this power supply intended for?
This model is suitable for LED lighting and moving sign applications. Because it is a constant-voltage 24V unit with TRIAC dimming support, it fits projects that need dimmable indoor LED power in a compact enclosed housing.
Can the Envo SC-30-24-US be used outdoors or in wet areas?
No. This power supply has an IP20 design and is specified for indoor installation in dry locations. It should be selected for environments where protection against water exposure is not required.
What input range and efficiency does this model offer?
The stated AC input range is 180-240VAC. The unit also includes active PFC and is rated for efficiency of up to 85%, which can help support stable performance in compatible indoor lighting applications.
What operating temperature range does the SC-30-24-US support?
The specified operating temperature range is -40°C to 60°C. That gives this model a wide environmental range for indoor dry-location use, provided the application stays within the product's stated limits.
How does this model compare with non-dimmable constant-voltage power supplies?
A key difference is that the SC-30-24-US supports AC phase-cut dimming, including leading-edge and trailing-edge TRIAC dimmers. It is also described as flicker-free, making it a stronger fit where dimming performance matters rather than simple fixed-output power only.
What warranty is provided for the Envo SC-30-24-US?
The listed warranty period for this model is 5 years. For buyers comparing commercial LED power supplies, that makes the warranty term a meaningful part of the overall product value for long-term indoor use.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other SC-30 Models
1 other model| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Envo SC-30-24 Power Supply 30W 24V - Triac dimmable 1.25A | 30W | 24V | 1.25A | Indoor | View |
