Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

ILLUMAX LED Strip ECO Series

120LEDs/m, 9.6W/m, 12V, cuttable length 25mm

SKU:

3528-1201200SCX-CW

Length

100 Centimeter

LED Colour

Cool White 6000K Natural White 4000K Warm White 3000K

Product variants

Please for Pricing

Notify me when it's back in stock

Description

Specifications:

Power Rating: 9.6W/m
Input Voltage: 12V DC
LED Density: 120 LEDs/m
Cutting Length: 25mm
Beaming Angle: 120 Degree
Width: 8mm
Lifetime: 50000hrs
Mounting: Standard: 3M Tape

Specifications

Brand

Illumax
Series

Illumax Eco Series
Power Rating

9.6 Watt
Operation Mode

Constant Voltage
Operating Temperature

-10°C~50°C
Warranty

2 Year
Width

0.8 cm
Height

0.2 cm
Weight

0.1 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What is the ILLUMAX LED Strip ECO Series designed for?

The ILLUMAX LED Strip ECO Series is a low-voltage LED strip suited to linear lighting applications where a compact 8mm-wide strip is useful. It is part of the ECO range, so it is positioned as a practical option for general LED strip lighting across commercial and trade-focused projects.

What are the main specifications of the ILLUMAX LED Strip ECO Series?

This LED strip is rated at 9.6W per metre and operates on 12V DC input. It has 120 LEDs per metre, a 120 degree beam angle, a 25mm cutting length, and an 8mm width. The product is also rated for a 50,000 hour lifetime and includes standard 3M tape mounting.

What colour temperature options are available in this product family?

This parent product family includes warm white 3000K, neutral white 4000K, and cool white 6000K variants. These options let buyers choose a warmer, more neutral, or crisper light appearance while staying within the same ECO Series product platform.

How does light output vary between the different variants?

The published lumen output differs by colour temperature within this family. The 3000K option is listed at 640 lm, the 4000K option at 660 lm, and the 6000K option at 780 lm. That means the cool white version has the highest stated brightness of the available variants.

Does the ILLUMAX LED Strip ECO Series include a driver, and can it be dimmed?

A driver is not included with this product family. The series is described as dimmable optional, which means dimming capability depends on the control setup and any compatible supporting components selected for the project.

What warranty is provided for the ILLUMAX LED Strip ECO Series?

This product family carries a 2-year warranty period. That warranty applies at the parent model level across the listed variants in this range.

Model	Power	LED Density	Cuttable	IP Rating
ILLUMAX LED Strip ECO+ Series	9.6W	120LEDs/m	50mm	Indoor	View
ILLUMAX LED Strip ECO Series - Waterproof IP68	9.6W	120LEDs/m	25mm	IP68	View
ILLUMAX LED Strip ECO+ Series - Waterproof IP68	9.6W	120LEDs/m	—	IP68	View
