ILLUMAX LED Strip ECO+ Series

120LEDs/m, 9.6W/m, 24V, cuttable length 50mm

SKU:

3528-1202400SCX-NW

Length

100 Centimeter

LED Colour

Natural White 4000K Cool White 6000K Warm White 3000K

Product variants

Please for Pricing

Notify me when it's back in stock

Description

Power Rating: 9.6W/m
Input Voltage: 24V DC
LED Density: 120 LEDs/m
Cutting Length: 50mm
Beaming Angle: 120 Degree
Width: 10mm
Lifetime: 50000hrs
Mounting: Standard: 3M Tape

Specifications

Brand

Illumax
Series

Illumax Eco Series
Power Rating

9.6 Watt
Operation Mode

Constant Voltage
Operating Temperature

-10°C~50°C
Warranty

2 Year
Width

0.8 cm
Height

0.2 cm
Weight

0.1 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What are the main specifications of the iLLUMAX LED Strip ECO+ Series?

This LED strip family runs on 24V DC and uses 9.6W per metre. It has a density of 120 LEDs per metre, a 120-degree beam angle, and can be cut every 50mm. The strip is supplied in a 5m roll and is rated for a 50,000-hour lifetime.

What colour temperature options are available in this LED strip family?

This parent family includes Warm White 3000K, Neutral White 4000K, and Cool White 6000K options. These variants let buyers choose a warmer, more neutral, or cooler white appearance while staying within the same ECO+ Series platform. The underlying power rating and general format remain the same across the family.

How does light output vary between the available colour temperatures?

The listed variants differ slightly in lumen output. The 3000K version is rated at 790 lm, the 4000K version at 810 lm, and the 6000K version at 850 lm. This makes the cool white option the brightest of the variants shown.

Is a driver included with this LED strip?

No, this product family is listed with the driver not included. Buyers should account for a separate compatible 24V DC driver when planning a project. This applies across the variants shown for this parent model.

Is the iLLUMAX LED Strip ECO+ Series dimmable?

Yes, this family is described as dimmable with optional dimming control. That means dimming capability is available, but any required control gear is not implied to be included with the strip itself. The dimming status is the same across the variants provided.

What types of projects is this LED strip family suited for?

With 120 LEDs per metre, a 120-degree beam angle, and a 24V DC input, this strip family is suited to general linear lighting applications where consistent illumination is needed. It is positioned within LED strip and interior linear lighting categories, making it relevant for commercial and professional indoor lighting use. Buyers can then choose the preferred white colour temperature for the space.

What warranty is provided for this LED strip family?

The parent product family carries a 2-year warranty. This warranty period is also consistent across the child variants listed. It provides a clear baseline for commercial procurement and replacement planning.

Model	Power	LED Density	Cuttable	IP Rating
ILLUMAX LED Strip ECO Series	9.6W	120LEDs/m	25mm	Indoor	View
ILLUMAX LED Strip ECO Series - Waterproof IP68	9.6W	120LEDs/m	25mm	IP68	View
ILLUMAX LED Strip ECO+ Series - Waterproof IP68	9.6W	120LEDs/m	—	IP68	View
