Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

LED Strip ProPlus Dim to warm 224LEDs/m/m 9.6W/m 24V IP65 CRI>90

SKU:

Z-CC2216-2242465GLE-DTW-5

Length

500 Centimeter

LED Colour

Dim To Warm

Product variants

Please for Pricing

Notify me when it's back in stock

Description

• Plus Series using top quality material such as Epistar/San'an chip, Intermatix phosphor powder, ShinEtsu & Dow Corning glue, Heraeus 99.99% pure golden wire, pure copper & fresh plastic stand etc. as standard configuration. • It warms as it is dimmed in only 2 wires. Dim-to-Warm concept is to dim CCT from 3000K (or 2700K) to 1800K while its brightness is dimmed from 100% to 10% (according to different kinds of drivers) synchronously and smoothly, perfectly simulating the warmth and dimming curve of incandescent and halogen lamp, which create a comfortable and natural lighting performance. • Direct dimming with PWM (Pulse-Width Modulation) output type of driver, no remote controller, no receiver, no battery, simple and convenient wiring. • Decorating backlight and indirect lighting for showcase, shelf, cabinet, billboard, signage, hotel, garden, bridge, corridor, ceiling, stair, floor, cove, theatre, lift etc. IP65 rated

Specifications

Brand

Archilight
Series

Dim to Warm
Power Rating

9.6 Watt
Operation Mode

Constant Voltage
Operating Temperature

-10°C~50°C
Warranty

5 Year
Width

1.2 cm
Height

0.2 cm
Weight

0.2 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What is this LED strip best suited for?

This archilight ProPlus dim-to-warm LED strip is suited to interior linear lighting projects where warm dimming and high color quality are important. It dims from a warmer white range toward 1800K while brightness is reduced, creating a softer ambience for hospitality, residential, retail, and architectural accent lighting.

What does dim-to-warm mean on this LED strip?

Dim-to-warm means the strip shifts to a warmer color temperature as it is dimmed. This model is described as dimming from 3000K or 2700K down to 1800K while brightness reduces smoothly, depending on the driver used.

Is a driver included with this LED strip?

No. The product data lists the driver as not included, so the driver must be selected separately for the project. The strip is specified for 24V power input and dim-to-warm control.

Can this LED strip be used in damp or outdoor-rated linear lighting areas?

This model is rated IP65, which indicates protection against dust and low-pressure water exposure. It is listed in outdoor and outdoor linear lighting categories, but project suitability still depends on the complete fixture, enclosure, driver choice, and site conditions.

How bright and efficient is this LED strip?

The parent model is rated at 9.6W/m with 224 LEDs per meter. The listed child variant shows 3400 lm brightness, and the product is specified with CRI greater than 90 for stronger color rendering.

Are there variant differences within this parent model?

The provided child data shows one variant under this parent product model. No separate CCT, beam angle, finish color, lifetime, or cut-out differences are listed for comparison.

What physical size should be considered for this strip?

The product data lists the strip at 12 mm wide and 2 mm high. The listed weight is 0.2 kg, which is useful for product comparison and planning at the specification stage.

What warranty does this LED strip include?

This archilight ProPlus dim-to-warm LED strip is listed with a 5 year warranty period. The product description also notes premium component materials such as Epistar/San'an chips, Intermatix phosphor powder, and high-quality glue and conductor materials.

Model	Power	LED Density	Cuttable	IP Rating
LED Strip ProPlus Dim to warm 224LEDs/m 9.6W/m 24V IP20 CRI>90	9.6W	224LEDs/m	62.5mm	Indoor	View
