Description
Description
Features:
- Housing made from SAMSUNG/COVESTRO's V0 flame retardant PC materials.
- Ultra small, thin and lightweight, screwless end cap
- Change the output current, DALI address and other parameters on the NFC programmer or via the App, and sync the parameters to the driver.
- Set the DALI group, scene in the advanced DALI template.
- Set the output current down to 1mA.
- DALI bus standard IEC62386-101, 102, 207.
- Class 2 LED driver, Safety Extra Low Voltage (SELV).
- Soft-on and fade-in dimming function enhances your visual comfort.
- T-PWM™ dimming technology allows quality and high-end lighting.
- The whole dimming process is flicker-free with high frequency
- exemption level.
- Comply with the EU’s ErP Directive, networked standby<0.5W.
- Multiple current levels, wide voltage range, suitable for LEDs with different power
- When there is no load, the output will be 0V to prevent damage to LEDs due to poor contact.
- Overheat, over voltage, overload, short circuit protection and automatic recovery.
- Suitable for ClassⅠ/Ⅱ/Ⅲ indoor light fixtures.
- Normal service life can reach 100,000 hours.
- 5-year warranty (Rubycon capacitor).
General Specification
AC input voltage range
220-240Vac
AC inrush current (max.)
Cold start 15A(Test twidth=300us tested under 50% Ipeak)/230Vac
Over-heat Protection
Intelligently adjust or turn off the current output if the PCB temperature ≥110°C. When the PCB temperature <90°C, automatically recover normal output
Over Load Protection
Automatically protect the device when the load exceeds 102% of the rated power. Automatically recover once load is reduced
Short Circuit Protection
Enter hiccup mode if short circuit occurs, and recover automatically
Over voltage protection
Automatically protect the device when voltage exceeds the no-load voltage. It can be recovered automatically
Withstand voltage
I/P-O/P: 3750Vac
Working temperature
ta:-20~45°C tc:90°C
Safety standards
CCC - China - GB19510.1,GB19510.14
TUV - Germany - EN61347-1,EN61347-2-13,EN62493
CE - European Union - EN61347-1,EN61347-2-13,EN62384
KC - Korea - KC61347-1,KC61347-2-13
RCM - Australia - AS61347-1,AS61347-2-13
ENEC - Europe - EN61347-1,EN61347-2-13,EN62384
CB - CB member states - IEC61347-1,IEC61347-2-13
EAC - Russia - IEC61347-1,IEC61347-2-13
UKCA - Britain - BS EN 61347-2-13:2014+A1:2017,BS EN 61347-1:2015+A1:2021
Dimension (LxWxH)
119×22×20mm
Specifications
Specifications
-
BrandLtech
-
SeriesLtech DALI Series
-
Power Rating6.3 Watt
-
Output Voltage30 Volt
-
Rated Current0.3 Ampere
-
Input Voltage220V~240V
-
Standards MetCB,CCC,CE,EAC,ENEC,KC,SELV,TUV
-
Operation ModeConstant Current
-
Operating Temperature-20°C~45°C
-
Warranty5 Year
-
Length11.9 cm
-
Width2 cm
-
Height2.2 cm
-
Weight0.01 kg
