Mean Well DCWN06A-12 DC-DC Converter - 6W 9~18V DC in 12V out 250mA
Please Login for Pricing
Description
Description
The DCWN06A is a 6W Mean Well. power converter. and an input range of 9~18Vdc.
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDCWN Series
-
Power Rating6 Watt
-
Output Voltage12 Volt
-
Rated Current0.25 Ampere
-
Input Voltage9V~18V
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length3.18 cm
-
Width2.03 cm
-
Height1.02 cm
-
Weight0.01 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the DCWN06A-12 typically used for?
The Mean Well DCWN06A-12 is typically used as a compact isolated DC-DC converter for generating a regulated 12V output from a 9-18V DC input. With 6W rated power and 0.25A output current, it is suitable for low-power 12V auxiliary, control, and interface circuits.
Is the DCWN06A-12 a good fit for 12V auxiliary rails from a 12V-class input source?
Yes. The DCWN06A-12 is designed for a 9-18V input range and provides a regulated 12V output at up to 0.25A, making it appropriate for low-power isolated 12V rails when the load stays within its 6W rating.
What makes the DCWN06A-12 useful in compact isolated systems?
The DCWN06A-12 combines a DIP24 package, 3KVDC I/O isolation, no minimum load requirement, and high typical efficiency. That makes it useful in compact industrial or embedded systems that need isolation and stable low-power conversion.
Can the DCWN06A-12 be used in demanding thermal environments?
Yes. The published operating temperature range is -40°C to +90°C, supporting use in broad environmental conditions when the overall system is designed within the converter's ratings.
How does the DCWN06A-12 compare with nearby DCWN models?
The DCWN06A-12 is the 12V output member of the 6W 06A group. The DCWN06A-05 and DCWN06A-15 provide 5V and 15V outputs, while 3W models such as the DCWN03A-12 or DCWN03E-12 offer lower output power. The best choice depends on the required output voltage and power margin.
