Mean Well DCWN06A-15 DC-DC Converter - 6W 9~18V DC in 15V out 200mA
Please Login for Pricing
Description
Description
The DCWN06A is a 6W Mean Well. power converter. and an input range of 9~18Vdc.
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDCWN Series
-
Power Rating6 Watt
-
Output Voltage15 Volt
-
Rated Current0.2 Ampere
-
Input Voltage9V~18V
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length3.18 cm
-
Width2.03 cm
-
Height1.02 cm
-
Weight0.01 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the DCWN06A-15 typically used for?
The Mean Well DCWN06A-15 is typically used as a compact isolated DC-DC converter for generating a regulated 15V output from a 9-18V DC input. With 6W rated power and 0.2A output current, it is intended for low-power 15V auxiliary and control applications.
Is the DCWN06A-15 a good fit for low-power 15V circuits from a 12V-class DC input?
Yes. The DCWN06A-15 converts a 9-18V DC input into a regulated 15V output at up to 0.2A, making it suitable for low-power isolated 15V rails when the application stays within the unit's 6W capability.
Why choose the DCWN06A-15 over a 3W 15V DCWN converter?
The key benefit is greater output headroom. At 6W, the DCWN06A-15 can support a larger 15V load than 3W models such as the DCWN03A-15 or DCWN03E-15, while keeping the same compact isolated module format.
Can the DCWN06A-15 operate across wide temperatures?
Yes. The published working temperature range is -40°C to +90°C, allowing use in a broad range of industrial and embedded environments when the converter is used within specification.
How does the DCWN06A-15 compare with the other 06A models?
The DCWN06A-15 is the 15V output variant of the 6W 06A family, while the DCWN06A-05 and DCWN06A-12 provide 5V and 12V outputs from the same 9-18V input range. Selection mainly depends on the output voltage your low-power circuit needs.
