Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well DCWN06C-05 DC-DC Converter - 6W 36~72V DC in 5V out

SKU:

DCWN06C-05

Please for Pricing

Notify me when it's back in stock

Description

Features

DIP24 package with industry standard pinout

2:1 wide input range

Operating temperature range -40~+90°C

No minimum load required

Comply to BS EN/EN55032 radiated Class A without additional components

High efficiency up to 87%

Protections: Short circuit(Continuous)/Overload/Input under voltage

3KVDC I/O isolation

3 years warranty

General Specification

Voltage set point accuracy	±1.5% (max.)
Line regulation	±0.5% (max.)
Load regulation	Single output models:±0.5%, Dual output models:±1%
Overload protection	120%~250%, auto-recovery
Efficiency	87% (typical)
Short circuit protection	Continuous, auto-recovery
I/O isolation voltage	I/P-O/P:3KVDC
I/O isolation resistance	I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
Isolation capacitance	250pF (max.)
Working temperature	-40~+90°C
Storage temperature	-40°C to +105°C
EMC	Compliance to EN55032 class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.03% / ℃ (0 ~ 85℃)
Dimension (LxWxH) (mm)	31.820.310.2mm (1.250.80.4 inch)
Case material	Non-conductive black plastic(UL 94V-0 rated)

Specifications

Brand

Mean Well
Series

DCWN Series
Power Rating

6 Watt
Output Voltage

5 Volt
Rated Current

0.5 Ampere
Input Voltage

36V~72V
Standards Met

CE,EAC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

3.18 cm
Width

2.03 cm
Height

1.02 cm
Weight

0.01 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the DCWN06C-05 to power a 5V industrial controller or sensor from a 36-72V DC bus?

This model is intended for constant-voltage 5V applications where the source is within the 36-72V DC input range. It can supply up to 0.5A with a 6W power rating, so it fits low-power industrial controllers, sensors, or interface boards that stay within those limits.

Is the DCWN06C-05 a good fit for embedded electronics inside industrial equipment?

It is suited to embedded 5V electronics that need a regulated output from a 36-72V DC source. Its compact 31.8 x 20.3 x 10.2 mm size and 0.0125 kg weight make it appropriate where board space and enclosure space are limited.

Can this 5V converter support low-power automation or communications modules?

It can support 5V automation or communications modules if their load stays at or below 0.5A and 6W. That makes it appropriate for small control, monitoring, or interface functions rather than higher-current 5V loads.

How does the DCWN06C-05 compare with the other DCWN06C models?

All three DCWN06C models are rated at 6W and share the same 31.8 x 20.3 x 10.2 mm dimensions, 0.0125 kg weight, and -40C to +90C operating temperature range. The DCWN06C-05 outputs 5V at 0.5A, the DCWN06C-12 outputs 12V at 0.25A, and the DCWN06C-15 outputs 15V at 0.2A.

Is the DCWN06C-05 suitable for outdoor or harsh-environment use?

The listed specs show an operating temperature range of -40C to +90C, which supports use across a wide temperature range. However, no IP rating is provided in the specs, so outdoor exposure or washdown suitability cannot be confirmed from this product data alone.
