Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well LDB-500LW DC/DC LED Driver CC 500mA - Buck-boost

contant current, buck-boost, high efficiency up to 91%, wire style

SKU:

LDB-500LW

Please for Pricing

Notify me when it's back in stock

Description

Features

DC/DC buck-boost converter

Constant current output: 300mA to 600mA

Wide input voltage: 9~36VDC

Wide output LED string voltage: 2~40VDC

High efficiency up to 91%

Comply with BS EN/EN55015 and FCC part15

Build-in PWM and remote ON/OFF control

Protections: Short circuit/Over temperature

Cooling by free air convection

Fully encapsulated with IP67 level for pin and wire style

Compact size

High reliability

Suitable for driving illumination LED

3 years warranty

General Specification

Current accuracy	±5%
Over temperature protection	Shut down, auto-recovery
Efficiency	90% (typical)
Short circuit protection	Regulated at rated output current
Working temperature	-40°C to +70°C
EMC	Compliance to EN55015 class B, EN61000-4-2,3,4,6,8, EAC TP TC 020
Temp. Coefficient	±0.03% / °C
Dimension (LxWxH) (mm)	31.8x20.3x12.2mm
Potting material	Expoxy(UL94-V0)

Specifications

Brand

Mean Well
Series

LDB Series
Power Rating

16 Watt
Output Voltage

32 Volt
Rated Current

0.5 Ampere
Input Voltage

9V~30V
Standards Met

CE,EAC
Operation Mode

Constant Current
Operating Temperature

-40°C~71°C
Warranty

3 Year
Length

3.18 cm
Width

2.03 cm
Height

1.22 cm
Weight

0.02 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can the LDB-500LW power a 500mA LED downlight module?

Yes, this is a constant current LED driver with a 500mA output, so it matches downlight modules rated for 500mA. The LED load still needs to remain within the 2-32V CC range and the 16W output rating.

Is the LDB-500LW suitable for illuminated sign modules or channel letters?

It can be used for signage modules or small LED arrays when the LEDs require 500mA constant current rather than constant voltage. The total LED forward voltage must stay inside the 2-32V constant current range.

Can this driver be used for a compact constant current LED array?

Yes, if the array is designed around 500mA operation and does not exceed 16W. The driver regulates current, so it is intended for constant current arrays rather than fixed-voltage LED strips.

How do I size LEDs for the LDB-500LW?

Use the 500mA output current and the 2-32V CC output range as the main sizing criteria. The exact number of LEDs depends on the forward voltage of each LED, so compatibility is based on the total LED voltage rather than a stated LED count.

Is the LDB-500LW appropriate for outdoor or sealed applications?

The IP67 Waterproof rating makes it appropriate for applications that need strong dust and water resistance. It is also rated for -40°C to +71°C operation, which supports use in challenging conditions.
