Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well LDB-600LW DC/DC LED Driver CC 600mA - Buck-boost

contant current, buck-boost, high efficiency up to 91%, wire style

SKU:

LDB-600LW

Please for Pricing

Notify me when it's back in stock

Description

Features

DC/DC buck-boost converter

Constant current output: 300mA to 600mA

Wide input voltage: 9~36VDC

Wide output LED string voltage: 2~40VDC

High efficiency up to 91%

Comply with BS EN/EN55015 and FCC part15

Build-in PWM and remote ON/OFF control

Protections: Short circuit/Over temperature

Cooling by free air convection

Fully encapsulated with IP67 level for pin and wire style

Compact size

High reliability

Suitable for driving illumination LED

3 years warranty

General Specification

Current accuracy	±5%
Over temperature protection	Shut down, auto-recovery
Efficiency	90% (typical)
Short circuit protection	Regulated at rated output current
Working temperature	-40°C to +70°C
EMC	Compliance to EN55015 class B, EN61000-4-2,3,4,6,8, EAC TP TC 020
Temp. Coefficient	±0.03% / °C
Dimension (LxWxH) (mm)	31.8x20.3x12.2mm
Potting material	Expoxy(UL94-V0)

Specifications

Brand

Mean Well
Series

LDB Series
Power Rating

18 Watt
Output Voltage

30 Volt
Rated Current

0.6 Ampere
Input Voltage

9V~28V
Standards Met

CE,EAC
Operation Mode

Constant Current
Operating Temperature

-40°C~71°C
Warranty

3 Year
Length

3.18 cm
Width

2.03 cm
Height

1.22 cm
Weight

0.02 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can the LDB-600LW be used with a 600mA LED downlight engine?

Yes, this driver outputs 600mA constant current, so it suits LED downlight engines rated for 600mA. The connected LED load needs to stay within the 2-30V constant current range and the 18W maximum output.

Is the LDB-600LW a fit for small high-brightness LED arrays?

Yes, it can be used for compact LED arrays that are specified for 600mA constant current operation. It is not a constant voltage driver, so it should not be used as a substitute for a fixed-voltage LED power supply.

Can this model work for outdoor signage lighting?

It can be a fit for outdoor signage modules that need 600mA constant current and stay within the 2-30V CC range. The IP67 Waterproof rating also supports applications where exposure to dust or water is a concern.

What LED load range does the LDB-600LW support?

This model delivers 600mA constant current with a 2-30V CC output range. The number of LEDs depends on the forward voltage of each LED, so compatibility should be checked by total LED voltage rather than by a fixed LED count.

Is the LDB-600LW rated for wide temperature exposure?

Yes, it is specified for operation from -40°C to +71°C. Combined with the IP67 Waterproof rating, that makes it suitable for use in exposed or demanding environments.

Model	Power	Voltage	Current	IP Rating
Mean Well LDB-600L DC/DC LED Driver CC 600mA - Buck-boost	18W	30V	0.6A	IP67	View
Mean Well LDB-500LW DC/DC LED Driver CC 500mA - Buck-boost	16W	32V	0.5A	IP67	View
Mean Well LDB-500L DC/DC LED Driver CC 500mA - Buck-boost	16W	32V	0.5A	IP67	View
Mean Well LDB-350LW DC/DC LED Driver CC 350mA - Buck-boost	14W	40V	0.35A	IP67	View
Mean Well LDB-350L DC/DC LED Driver CC 350mA - Buck-boost	14W	40V	0.35A	IP67	View
Mean Well LDB-300LW DC/DC LED Driver CC 300mA - Buck-boost	12W	40V	0.3A	IP67	View
Mean Well LDB-300L DC/DC LED Driver CC 300mA - Buck-boost	12W	40V	0.3A	IP67	View
