Mean Well LPC-35-1400 Power Supply 35W 1400mA
Please Login for Pricing
Description
Description
The LPC-35 is a 35W Mean Well DIN rail power converter with a 148mm profile (input range: 9~48V, operating temperature: -30~+70℃).
Key Features
- ✓ 148mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 9~48V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Over voltage
- ✓ Safety approvals: UL1310, CAN/CSA C22.2 No. 223-M91(except for LPC-35-700), IP67
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesLPC Series
-
Power Rating33.6 Watt
-
Output Voltage24 Volt
-
Rated Current1.4 Ampere
-
Input Voltage90V~264V
-
Standards MetCE,EAC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length14.8 cm
-
Width4 cm
-
Height3 cm
-
Weight0.34 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the LPC-35-1400 for a high-current LED downlight?
This driver can fit a LED downlight when the LED engine is specified for 1400mA constant current and the total forward voltage remains within 9-24V. Its 33.6W output suits compact but higher-current downlight assemblies. Because it is a constant current model, it should not be substituted for a constant voltage supply.
Is the LPC-35-1400 suitable for small high-output signage modules?
It can be suitable for small high-output signage modules if the LED load requires 1400mA constant current and falls in the 9-24V CC range. The lower maximum voltage means it is intended for lower-voltage assemblies than some other siblings. It should only be used with constant current LED modules.
Can this driver power a compact LED array that needs more drive current?
Yes, if the compact LED array is designed for 1400mA constant current and its total forward voltage is between 9V and 24V. The 33.6W rating makes it appropriate for higher-current small arrays that stay within that narrower voltage window. Loads designed for constant voltage input are not a match.
How do I know whether my LEDs will work with the LPC-35-1400?
The LED load must require 1400mA constant current, and its combined forward voltage must fit inside the 9-24V constant current range. The number of LEDs depends on the forward voltage of each LED, so there is no fixed LED count that applies to every build. Selection should be based on the total load voltage and current requirement together.
How does the LPC-35-1400 compare with the other LPC-35 current options?
The LPC-35-700 is 700mA with a 9-48V CC range and 33.6W, the LPC-35-1050 is 1050mA with a 9-30V range and 31.5W, and the LPC-35-1400 is 1400mA with a 9-24V range and 33.6W. The family differences are mainly output current and how much constant current voltage range is available. Higher current versions in this group operate over lower voltage ranges.
Is the LPC-35-1400 appropriate for outdoor or damp conditions?
It is rated IP67 waterproof, which supports use where water and dust resistance are required. The specified operating temperature range is -30°C to +70°C, so it is built for a broad range of environmental conditions. That makes it suitable for tougher indoor or outdoor service environments within those ratings.
Other LPC-35 Models
2 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well LPC-35-700 Power Supply 35W 700mA | 33.6W | 48V | 0.7A | IP67 | View |
| Mean Well LPC-35-1050 Power Supply 35W 1050mA | 31.5W | 30V | 1.05A | IP67 | View |
