Can I use the MDS20C-12 to power a 12V industrial control board from a 36-75VAC source?

Yes, this converter is designed for a 36-75VAC input and provides a constant 12V output. It is suited to low-power control electronics as long as the load stays within 20W and 1.67A.

Is the MDS20C-12 a good fit for embedded equipment that needs regulated 12V in a compact space?

It can be a practical fit where board space is limited because the unit measures 50.8 x 25.4 x 12.0 mm and weighs 0.03 kg. The output is constant voltage at 12V, with up to 1.67A available within its 20W rating.

Can this 12V DC-DC converter be used for low-power automation devices on a higher-voltage bus?

Yes, if the source is within 36-75VAC and the automation load needs a stable 12V supply. The key sizing limits are 20W total power and 1.67A maximum output current.

Will the MDS20C-12 handle wide-temperature industrial environments?

The specified operating temperature range is -40 degrees C to +90 degrees C, which covers very cold and very hot operating conditions. No IP rating is listed in the provided specs, so these specs alone do not identify it as an exposed outdoor-rated unit.

How does the MDS20C-12 compare with the other MDS20C output options?

All listed MDS20C siblings are 20W models. The MDS20C-05 is 5V at 4A, the MDS20C-12 is 12V at 1.67A, the MDS20C-15 is 15V at 1.33A, and the MDS20C-24 is 24V at 833A.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well MDS20C-12 DC-DC Converter - 20W - 36~75V in 12V out 1.67A

SKU:

MDS20C-12

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The MDS20C is a 20W Mean Well power converter (input range: 9~18Vdc).

Key Features

✓ Input voltage range: 9~18Vdc
✓ Protections: Short circuit / Overload / Under voltage
✓ Safety approvals: IEC60601-1(LVD) 3 edition, EAC TP TC 004
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well MDS20C-24 DC-DC Converter - 20W - 36~75V in 24V out 833mA	20W	24V	0.83A	Indoor	View
Mean Well MDS20C-15 DC-DC Converter - 20W - 36~75V in 15V out 1.33A	20W	15V	1.33A	Indoor	View
Mean Well MDS20C-05 DC-DC Converter - 20W - 36~75V in 5V out 4A	20W	5V	4A	Indoor	View
Mean Well MDS20B-24 DC-DC Converter - 20W - 18~36V in 24V out 833mA	20W	24V	0.83A	Indoor	View
Mean Well MDS20B-15 DC-DC Converter - 20W - 18~36V in 15V out 1.33A	20W	15V	1.33A	Indoor	View
Mean Well MDS20B-12 DC-DC Converter - 20W - 18~36V in 12V out 1.67A	20W	12V	1.67A	Indoor	View
Mean Well MDS20B-05 DC-DC Converter - 20W - 18~36V in 5V out 4A	20W	5V	4A	Indoor	View
Mean Well MDS20A-24 DC-DC Converter - 20W - 9~18V in 24V out 833mA	20W	24V	0.83A	Indoor	View
Mean Well MDS20A-15 DC-DC Converter - 20W - 9~18V in 15V out 1.33A	20W	15V	1.33A	Indoor	View
Mean Well MDS20A-12 DC-DC Converter - 20W - 9~18V in 12V out 1.67A	20W	12V	1.67A	Indoor	View
Mean Well MDS20A-05 DC-DC Converter - 20W - 9~18V in 5V out 4A	20W	5V	4A	Indoor	View
