What dimming inputs are supported by the NPF-60D-42?

The NPF-60D-42 includes built-in 3-in-1 dimming that accepts PWM signal, 0–10V analog, and resistance (potentiometer) control. All three methods are natively supported without external dimming accessories.

Can the NPF-60D-42 drive dimmable 42V LED modules in outdoor facade lighting?

Yes. The NPF-60D-42 delivers 60.06W at 42V with a constant current of 1.43A and a CC range of 25–42V. Its IP67 rating and -40°C to +85°C operating range make it well suited for outdoor facade or architectural lighting where dimming is needed.

How does the NPF-60D-42 compare to the NPF-60-42?

The NPF-60D-42 and NPF-60-42 are electrically identical (60.06W, 42V, 1.43A, IP67, CC range 25–42V, 150.0 × 53.0 × 35.0 mm, 0.49 kg). The NPF-60D-42 adds built-in 3-in-1 dimming; the NPF-60-42 is a fixed-output driver.

Is the NPF-60D-42 suitable for outdoor installation without a secondary enclosure?

Yes. The NPF-60D-42 is IP67-rated for dust-tight and temporary water immersion protection, and operates from -40°C to +85°C, covering a wide range of outdoor climatic conditions without requiring a secondary weatherproof housing.

Does the NPF-60D-42 carry UL certification for North American use?

Yes. The NPF-60D-42 holds UL, CB, CCC, CE, EAC, and ENEC certifications, supporting deployment in North American and European markets, and includes a 5-year warranty.

Mean Well NPF-60D-42 Power Supply 60W 42V - Dimmable | Auckland Distributor

The NPF-60D is a 60W Mean Well DIN rail power converter with a 150mm profile (input range: 90~305VAC, operating temperature: -40~+80℃).

Key Features

✓ 150mm width — DIN rail TS-35 compatible
✓ Input voltage range: 90~305VAC
✓ 3.75KVAC reinforced I/O isolation
✓ Wide operating temperature: -40~+80℃
✓ Protections: Short circuit / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: UL8750(type”HL”), CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent, IP67
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well NPF-60D-54 Power Supply 60W 54V - Dimmable 1.12A	60.48W	54V	1.12A	IP67	View
Mean Well NPF-60D-48 Power Supply 60W 48V - Dimmable 1.25A	60W	48V	1.25A	IP67	View
Mean Well NPF-60D-36 Power Supply 60W 36V - Dimmable 1.67A	60.12W	36V	1.67A	IP67	View
Mean Well NPF-60D-30 Power Supply 60W 30V - Dimmable 2A	60W	30V	2A	IP67	View
Mean Well NPF-60D-24 Power Supply 60W 24V - Dimmable 2.5A	60W	24V	2.5A	IP67	View
Mean Well NPF-60D-20 Power Supply 60W 20V - Dimmable 3A	60W	20V	3A	IP67	View
Mean Well NPF-60D-15 Power Supply 60W 15V - Dimmable 4A	60W	15V	4A	IP67	View
Mean Well NPF-60D-12 Power Supply 60W 12V - Dimmable 5A	60W	12V	5A	IP67	View
