Mean Well RCP-1600-12 power supply 1600W 12V 125A

high efficiency up to 93%, output voltage and current programmable, active currecnt sharing up to 8000W, support hot swap
SKU:
RCP-1600-12

|

Description

Features

Universal AC input / Full range
Built-in active PFC function
High efficiency up to 93%
Forced air cooling by built-in DC fan
Output voltage and constant current level programmable
Built-in OR-ing FET, support hot swap (hot plug)
Active current sharing up to 8000W (3 units) in one 19" rack shelf
Built-in I²C interface, PMBus protocol
Protections: Short circuit / Over current / Over voltage / Over temperature
Optional conformal coating
5 years warranty

General Specification

AC input voltage range 90~264VAC | 127 ~ 370VDC
DC adjustment range ±3% rated output voltage
Overload protection 105%~115% constant current limiting, auto-recovery
Over-voltage protection 110%~135% rated output voltage
Setup, rise, hold up time 1500ms, 60ms/230VAC at full load
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC (0.5KVAC for 12V)
Working temperature -20~+70°C (refer to output derating curve)
Safety standards UL62368-1, CAN/CSA C22.2 , TUV EN62368-1 EAC TP TC 004 approved
EMC standards EN55022 class B, EN61204-3, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 heavy industry level
Dimension (LxWxH) (mm) 300 x 85 x 41 mm
Packing 1.87Kg; 6pcs/12.2Kg/1.16CUFT
CASE: 952A

Specifications

  • Brand
    Mean Well
  • Series
    RCP Series
  • Power Rating
    1500 Watt
  • Output Voltage
    12 Volt
  • Rated Current
    125 Ampere
  • Input Voltage
    90V~264V
  • Standards Met
    CB,CE,EAC,TUV,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -30°C~70°C
  • Warranty
    5 Year
  • Length
    30 cm
  • Width
    8.5 cm
  • Height
    4.1 cm
  • Weight
    1.87 kg
