Mean Well RCP-1600-24 power supply 1600W 24V 67A
Please Login for Pricing
Description
Description
The RCP-1600 is a 1600W Mean Well power converter (input range: 90~264VAC).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ Safety approvals: UL62368-1, TUV EN62368-1 EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesRCP Series
-
Power Rating1608 Watt
-
Output Voltage24 Volt
-
Rated Current67 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty5 Year
-
Length30 cm
-
Width8.5 cm
-
Height4.1 cm
-
Weight1.87 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the RCP-1600-24 for 24V PLC, industrial I/O, or automation systems?
Yes, this is a 24V constant-voltage model rated for 1608W and 67A, which makes it suitable for larger 24V automation and control loads. Its 90-264VAC input range also supports deployment across varied AC supply conditions.
Is the RCP-1600-24 suitable for powering 24V embedded systems or industrial computing equipment?
It can fit embedded and industrial computing environments that standardize on 24V DC and need substantial current headroom, because it delivers up to 67A. Programmable output voltage and current can also help where the 24V DC bus must be tuned within the product's supported settings.
Can this model work for centralized 24V DC power in a rack or modular equipment platform?
Yes, the RCP-1600-24 is built for dense power applications with a 300.0 x 85.0 x 41.0 mm chassis and 1.87 kg weight. Active current sharing up to 8000W and hot-swap support make it relevant for modular 24V DC power systems that need expansion or redundancy.
Can the RCP-1600-24 be used outdoors or in wide-temperature indoor environments?
The specified operating temperature range is -30°C to +70°C, which supports demanding indoor temperature conditions. No IP rating is provided in the specs, so outdoor exposure resistance is not confirmed from the listed data.
What are the main differences between the RCP-1600-24 and the other RCP family outputs?
The listed 24V models are RCP-1000-24 at 960W and 40A, RCP-1600-24 at 1608W and 67A, and RCP-2000-24 at 1920W and 80A. The listed 12V models are RCP-1000-12 at 720W and 60A, RCP-1000-12-C at 1000W and 60A, RCP-1600-12 at 1500W and 125A, RCP-1UT at 3000W and 60A, and RCP-2000-12 at 1200W and 100A. The listed 48V models are RCP-1000-48 at 1008W and 21A, RCP-1600-48 at 1608W and 33.5A, and RCP-2000-48 at 2016W and 42A.
Other RCP-1600 Models
2 other models| Model | Power | Voltage | Current | |
|---|---|---|---|---|
| Mean Well RCP-1600-48 power supply 1600W 48V 33.5A | 1608W | 48V | 33.5A | View |
| Mean Well RCP-1600-12 power supply 1600W 12V 125A | 1500W | 12V | 125A | View |
