Mean Well RSP-200-7.5 Power Supply 200W 7.5V 26.7A

1U low profile with active PFChigh efficiency

SKU:

RSP-200-7.5

Log in to see price Trade pricing & online ordering for account holders

Select model — 5 in this family

RSP-200-7.5

RSP-75-7.5 75W 7.5V Backorder

RSP-100-7.5 100W 7.5V Backorder

RSP-150-7.5 150W 7.5V Backorder

RSP-200-7.5 200W 7.5V Backorder

RSP-320-7.5 300W 7.5V Backorder

Product variants

Notify me when it's back in stock

The RSP-200 is a 200W Mean Well DIN rail power converter with a 215mm profile (input range: 88~264VAC).

Key Features

✓ 215mm width — DIN rail TS-35 compatible
✓ Input voltage range: 88~264VAC
✓ DC output voltage adjustable ±10%
✓ 3KVAC reinforced I/O isolation
✓ Protections: Overload / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: AS/NZS 60950.1
✓ 3 years warranty

Frequently Asked Questions

What 7.5V applications can the RSP-200-7.5 support at 26.7A?

The RSP-200-7.5 delivers 7.5V at 26.7A (200.25W) and is suited for 7.5V rail industrial control boards, specialty embedded systems, CNC machine logic supplies, and multi-board 7.5V distribution panels. At nearly 27A it provides substantially more current than the RSP-150-7.5 at 20A. The 88–264VAC input accommodates worldwide mains.

How does the RSP-200-7.5 compare to the RSP-100-7.5 and RSP-150-7.5?

The RSP-100-7.5 delivers 7.5V at 13.5A (101.25W, 179mm). The RSP-150-7.5 delivers 7.5V at 20A (150W, 199mm). The RSP-200-7.5 delivers 7.5V at 26.7A (200.25W, 215mm). All are 1U low-profile with 30mm height. The RSP-200-7.5 is the highest-current 7.5V option in this platform family.

Is the RSP-200-7.5 compatible with Australian and New Zealand market requirements?

Yes. The RSP-200-7.5 holds c_rcm certification alongside BSMI, CB, CCC, CE, EAC, TÜV, and UL, making it eligible for deployment in Australia and New Zealand.

What is the operating temperature range of the RSP-200-7.5?

The RSP-200-7.5 is rated from -30°C to +70°C ambient, identical to all other RSP-200 models. No IP ingress rating is provided; the unit must be enclosed for protection in dusty or wet environments.

What are all the RSP-200 series voltage options?

The RSP-200 series voltage options are: RSP-200-2.5 (100W/2.5V/40A), RSP-200-3.3 (132W/3.3V/40A), RSP-200-4 (160W/4V/40A), RSP-200-5 (200W/5V/40A), RSP-200-7.5 (200.25W/7.5V/26.7A), RSP-200-12 (200.4W/12V/16.7A), RSP-200-13.5 (201.15W/13.5V/14.9A), RSP-200-15 (201W/15V/13.4A), RSP-200-24 (200W/24V/8.4A), RSP-200-27 (200W/27V/7.5A), RSP-200-36 (200.16W/36V/5.56A), RSP-200-48 (200W/48V/4.2A).

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current
Mean Well RSP-200-24 Power Supply 200W 24V 8.4A	200W	24V	8.4A	View
Mean Well RSP-200-5 Power Supply 200W 5V 40A	200W	5V	40A	View
Mean Well RSP-200-48 Power Supply 200W 24V 4.2A	200W	48V	4.2A	View
