Mean Well SKM50B-15 DC-DC Converter - 50W - 18~36V in 15V out
Please Login for Pricing
Description
Description
The SKM50B is a 50W Mean Well power converter (input range: 18~36VDC).
Key Features
- ✓ Input voltage range: 18~36VDC
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Under voltage
- ✓ Safety approvals: 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating50 Watt
-
Output Voltage15 Volt
-
Rated Current3.33 Ampere
-
Input Voltage18V~36V
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~75°C
-
Warranty2 Year
-
Length5.08 cm
-
Width2.54 cm
-
Height1.37 cm
-
Weight0.04 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SKM50B-15 to power 15V industrial sensors or control modules from an 18-36VAC source?
Yes, this model is intended for constant-voltage 15V loads when the available input is 18-36VAC. It can supply up to 3.33A with a 50W power rating, which fits many compact industrial control and sensing applications within that load range.
Is the SKM50B-15 suitable for embedded equipment that needs a regulated 15V rail in a compact space?
It can be a practical fit for embedded systems that need a constant 15V output and stay within 3.33A and 50W. Its compact 50.8 × 25.4 × 13.7 mm size and 0.043 kg weight help where board or enclosure space is limited.
Can this converter be used in automation panels that start with 18-36VAC and need 15V output?
Yes, that matches the published operating range of this unit. It accepts 18-36VAC input and provides a constant 15V output up to 3.33A, so it is aligned with automation applications that need a stable 15V auxiliary rail within 50W.
Is the SKM50B-15 appropriate for 15V instrumentation or monitoring equipment?
It can be appropriate when the equipment requires constant-voltage 15V power and the total demand does not exceed 3.33A or 50W. The CE, c_emc, and FCC certifications may also matter in regulated industrial or electronic environments.
How does the SKM50B-15 compare with other SKM50B models?
Within the SKM50B series, all listed siblings are 50W models. The SKM50B-05 provides 5V at 10A, the SKM50B-12 provides 12V at 4.17A, and the SKM50B-15 provides 15V at 3.33A. The main selection difference is the output voltage and corresponding current rating.
Can the SKM50B-15 be used in hot or cold industrial environments?
Its operating temperature range is -40°C to +75°C, so it is designed for a wide temperature span. The provided specs do not list an IP rating, so temperature capability is clear, but indoor versus exposed outdoor use should be judged separately from enclosure protection.
Other SKM50 Models
9 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well SKM50W8-15 50W DC-DC Converter 15VDC | — | — | — | Indoor | View |
| Mean Well SKM50W8-12 50W DC-DC Converter 12VDC | — | — | — | Indoor | View |
| Mean Well SKM50W8-05 50W DC-DC Converter 5VDC | — | — | — | Indoor | View |
| Mean Well SKM50W8-03 50W DC-DC Converter 3.3VDC | — | — | — | Indoor | View |
| Mean Well SKM50C-15 DC-DC Converter - 50W - 36~75V in 15V out | 50W | 15V | 3.33A | Indoor | View |
| Mean Well SKM50C-12 DC-DC Converter - 50W - 36~75V in 12V out | 50W | 12V | 4.17A | Indoor | View |
| Mean Well SKM50C-05 DC-DC Converter - 50W - 36~75V in 5V out | 50W | 5V | 10A | Indoor | View |
| Mean Well SKM50B-12 DC-DC Converter - 50W - 18~36V in 12V out | 50W | 12V | 4.17A | Indoor | View |
| Mean Well SKM50B-05 DC-DC Converter - 50W - 18~36V in 5V out | 50W | 5V | 10A | Indoor | View |
