Mean Well SKM50C-05 DC-DC Converter - 50W - 36~75V in 5V out
Please Login for Pricing
Description
Description
The SKM50C is a 50W Mean Well power converter (input range: 18~36VDC).
Key Features
- ✓ Input voltage range: 18~36VDC
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Under voltage
- ✓ Safety approvals: 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSKM Series
-
Power Rating50 Watt
-
Output Voltage5 Volt
-
Rated Current10 Ampere
-
Input Voltage36V~75V
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~75°C
-
Warranty2 Year
-
Length5.08 cm
-
Width2.54 cm
-
Height1.37 cm
-
Weight0.04 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SKM50C-05 to derive 5V power for embedded controllers from a 36-75VAC source?
Yes, this model is designed for constant-voltage 5V output from a 36-75VAC input range. It can deliver up to 10A with a 50W rating, which suits higher-current 5V embedded or logic-driven loads within that limit.
Is the SKM50C-05 suitable for industrial logic boards or digital electronics that need a heavier 5V rail?
It is a stronger fit than lower-current 5V converters because it is rated for 10A at 5V, up to 50W total. That makes it relevant for digital electronics, controller boards, or processing hardware that need a constant 5V supply from a 36-75VAC input source.
Can this model support 5V loads in automation or telecom-adjacent equipment with a 36-75VAC input range?
It can, as long as the downstream load needs constant-voltage 5V and remains within 10A and 50W. The 36-75VAC input range is the key fit factor for systems already operating in that available supply window.
Is the SKM50C-05 a good choice for compact 5V power conversion inside dense equipment?
It is suited to compact designs because the body is only 50.8 × 25.4 × 13.7 mm and weighs 0.043 kg. Those dimensions can help in dense electronic assemblies where a constant 5V, 10A output is needed without moving to a larger form factor.
What is the difference between the SKM50C-05 and other SKM50C versions?
The listed SKM50C siblings all share a 50W rating and 36-75VAC input range, but the outputs differ. The SKM50C-05 is 5V at 10A, the SKM50C-12 is 12V at 4.17A, and the SKM50C-15 is 15V at 3.33A. Selection comes down to the output voltage your load requires and the corresponding current available.
Can the SKM50C-05 be used in harsh temperature conditions or outdoor equipment?
Its operating temperature range is -40°C to +75°C, which supports use across a broad temperature span. The published specs do not include an IP rating, so the temperature range is defined, but exposed outdoor suitability is not established by the listed data alone.
