Mean Well SPA01B-05 DC-DC Converter - 1W - 18~36V in 5V out 200mA
Log in to see priceOverview
SPA01B-05 is the 5V output model of this series: rated power 1W, typical efficiency 77%.
Features
- Single in line package
- 2:1 wide input range
- 1500VDC I/O isolation
- Built-in EMI filter without external components
- Protections: Short circuit / Overload
- Cooling by free air convection
- 100% full load burn-in test
- Low cost / High reliability
- 2 years warranty
Specifications
OUTPUT
- DC VOLTAGE
- 5V
- CURRENT RANGE
- 20 ~ 200mA
- RATED POWER
- 1W
- RIPPLE & NOISE (max.)Note.2
- 60mVp-p
- LINE REGULATIONNote.3
- ±0.5%
- LOAD REGULATIONNote.4
- ±0.5%
- VOLTAGE ACCURACY
- ±2.0%
- SWITCHING FREQUENCY
- 100KHz min.
INPUT
- VOLTAGE RANGE
- 18 ~ 36VDC
- EFFICIENCY (Typ.)
- 77%
- DC CURRENT Full load
- 55mA
- DC CURRENT No load
- 10mA
- FILTER
- Capacitor Type
- PROTECTION
- Fuse recommended
PROTECTION (Note. 5)
- OVERLOAD
- 130 ~ 200% rated output power Protection type : Recovers automatically after fault condition is removed
- SHORT CIRCUIT
- All output equipped with short circuit Protection type : Recovers automatically after fault condition is removed
ENVIRONMENT
- WORKING TEMP.
- -40 ~ +90℃ (Refer to "Derating Curve")
- WORKING HUMIDITY
- 20% ~ 90% RH non-condensing
- STORAGE TEMP., HUMIDITY
- -40 ~ +105℃, 10 ~ 95% RH
- TEMP. COEFFICIENT
- ±0.05% / ℃ (0 ~ 50℃)
- VIBRATION
- 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes
SAFETY
- SAFETY STANDARDS
- EAC TP TC 020/2011 (EAC TP TC 004 for 48Vin type only) approved
- WITHSTAND VOLTAGE
- I/P-O/P:1.5KVDC
- ISOLATION RESISTANCE
- I/P-O/P: 100M Ohms / 500VDC / 25℃/ 70% RH
- ISOLATION CAPACITANCE
- 80pF max.
- EMC EMISSION
- Compliance to BS EN/EN55032 Class B, FCC part 15 Class B , EAC TP TC 020
- EMC IMMUNITY
- Compliance to BS EN/EN61000-4-2,3,4,5,6,8 light industry level, criteria A , EAC TP TC 020
OTHERS
- MTBF
- 500Khrs min. MIL-HDBK-217F(25℃)
- DIMENSION
- 17.4*7.75*11.1mm or 0.69"*0.30"*0.44" inch (L*W*H)
- PACKING
- 3g ; 28pcs/per tube, 2800pcs/100 tube/per carton
Test conditions and notes5
- 1.All parameters are specified at normal input, rated load, 25℃ 70% RH ambient.
- 2.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.
- 3.Line regulation is measured from low line to high line at rated load.
- 4.Load regulation is measured from 10% to 100% rated load.
- 5.Please prevent the converter from operating in overload or short circuit condition for more than 30 seconds.
Technical drawings
Downloads
Certificates5
Test reports1
FAQ
Can the SPA01B-05 be used for a low-power 5V logic or controller circuit in industrial equipment?
Yes, this model is intended for low-power 5V constant-voltage loads supplied from an 18-36VDC input range. It is rated at 1W total power with a listed 5V, 200mA output specification, so buyers should size the application to the published product specs.
Is the SPA01B-05 suitable for embedded electronics that need a compact 5V auxiliary rail?
It is suitable where an embedded board needs a small 5V auxiliary supply from an 18-36VDC source. The unit is physically compact at 17.4 × 11.1 × 7.75 mm and is designed as a constant-voltage 5V converter.
Can I use this converter for a 5V monitoring or signal-processing section inside an automation panel?
Yes, it can fit a small 5V monitoring or signal-processing section where the converter's published 1W rating matches the load requirement. It is intended for low-power internal electronics rather than larger 5V equipment loads.
Is the SPA01B-05 rated for outdoor or temperature-extreme locations?
Its operating temperature range is -40°C to +90°C, which supports use in equipment exposed to wide temperature variation. No IP rating is listed, so the product data does not by itself confirm suitability for outdoor or wet-location exposure.
How does the SPA01B-05 compare with the other SPA01B models?
The SPA01B family shown here shares the same 1W series format with different outputs. SPA01B-05 is listed at 5V and 200mA, SPA01B-12 at 12V and 83mA, and SPA01B-15 at 15V and 67mA.
