Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SPB09B-03 DC-DC Converter - 9W - 18~36V in 3.3V out

SKU:
SPB09B-03
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
|

Features

SIP8 package with industry-standard pinout
2:1 wide input range
Wide operating temperature range -40~+90°C
No minimum load required
High efficiency up to 89%
Protection: Short circuit(continuous)/Overload/Input under voltage
1.5KVDC I/O isolation

Remote ON/OFF control

9V model available(optional)

3 years warranty

General Specification

Voltage accuracy ±1.5%
Vibration 10 ~ 500Hz, 2G 10min./1 cycle, the period for 60min. each along X, Y, and Z axes
Cooling Free-air convection
Short circuit protection Continuous, auto-recovery
Working temperature -40°C to +90°C
EMC Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient 0.03% / ℃ (0 ~ 70℃)
Dimension (LxWxH) (mm) 24*9.6*11.2mm
Potting material UL 94V-0 rated
