Mean Well SPRN01L-15 DC-DC Converter - 1W - 4.75~5.5V in 15V out
Please Login for Pricing
Description
Description
Features
| SIP6 package with industry-standard pinout |
| Wide operating temperature range -40~+90°C |
| Comply to BS EN/EN55032 radiated Class B without additional components |
| Low cost |
| Protection: Short circuit |
| 1.5KVDC I/O isolation |
| 3 years warranty |
General Specification
| Voltage accuracy | ±3% |
| Vibration | 10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, and Z axes |
| Cooling | Free-air convection |
| Short circuit protection | SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max. |
| Working temperature | -40°C to +90°C |
| EMC | Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.05% / ℃ (0 ~ 71℃) |
| Dimension (LxWxH) (mm) | 19.6*7.1*10.14mm |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSPRN Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage4.75V~5.5V
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.96 cm
-
Width1.01 cm
-
Height0.71 cm
-
Weight0 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPRN01L-15 for a low-power 15V analog or industrial signal circuit?
Yes, it provides a 15V constant-voltage output from a 4.75~5.5V input range. With a 1W rating and 0.07A output current, it is intended for low-power 15V circuitry rather than higher-demand equipment.
Is the SPRN01L-15 suitable for embedded boards that need a small 15V rail?
It can be a fit for embedded or instrumentation designs that need a regulated 15V rail from a 4.75~5.5V input source. The 1W output rating keeps it in the category of low-power support electronics.
Can this model be used in compact automation modules with limited space?
Yes, the converter measures 19.6 × 10.14 × 7.1 mm and weighs 0.0025 kg, so it works well in compact assemblies. It is designed for constant-voltage 15V output in small industrial or embedded designs.
Would the SPRN01L-15 work in equipment installed in very hot or very cold areas?
Its operating temperature range is -40°C to +90°C, which supports use in equipment exposed to significant temperature variation. Since no IP rating is listed in the specs, it is better suited to protected indoor housings than direct outdoor exposure.
How does the SPRN01L-15 differ from the other SPRN01L versions?
All three SPRN01L models are 1W converters with the same 19.6 × 10.14 × 7.1 mm dimensions, 0.0025 kg weight, and -40°C to +90°C operating range. The difference is output: SPRN01L-05 is 5V, SPRN01L-12 is 12V at 0.08A, and SPRN01L-15 is 15V at 0.07A.
