Mean Well SPRN01N-05 DC-DC Converter - 1W - 22.8~26.4V in 5V out
Please Login for Pricing
Description
Description
Features
| SIP6 package with industry-standard pinout |
| Wide operating temperature range -40~+90°C |
| Comply to BS EN/EN55032 radiated Class B without additional components |
| Low cost |
| Protection: Short circuit |
| 1.5KVDC I/O isolation |
| 3 years warranty |
General Specification
| Voltage accuracy | ±3% |
| Vibration | 10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, and Z axes |
| Cooling | Free-air convection |
| Short circuit protection | SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max. |
| Working temperature | -40°C to +90°C |
| EMC | Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.05% / ℃ (0 ~ 71℃) |
| Dimension (LxWxH) (mm) | 19.6*7.1*10.14mm |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSPRN Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage22.8V~26.4V
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.96 cm
-
Width1.01 cm
-
Height0.71 cm
-
Weight0 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPRN01N-05 to step down a 22-26VAC source for a 5V embedded controller?
Yes, it is intended for constant-voltage 5V output when the input is within the listed 22-26VAC range. Because the unit is rated at 1W, it is best suited to low-power embedded control or logic sections rather than heavier 5V loads.
Is this a fit for powering low-power industrial sensors or interface electronics from a higher-voltage control supply?
It can fit low-demand industrial electronics that need a regulated 5V rail from a 22-26VAC source. The main limit is the 1W output rating, so it is more appropriate for small sensor, monitoring, or interface functions than broad 5V distribution.
Could the SPRN01N-05 work for compact automation or PLC-adjacent logic circuits?
For automation systems that need a small auxiliary 5V rail, this converter can be suitable if the upstream source is 22-26VAC. Its 1W capacity keeps it in the category of light logic or support circuitry, not larger PLC expansion or high-draw 5V devices.
Can this converter be used in equipment exposed to wide temperature swings?
The listed operating temperature range is -40°C to +90°C, which supports use in demanding temperature environments. Since no IP rating is provided in the specs, it should generally be treated as an indoor or enclosure-protected component rather than a bare outdoor part.
What is the difference between the SPRN01N-05, SPRN01N-12, and SPRN01N-15?
All three listed SPRN01N models are 1W converters in the same series. The SPRN01N-05 provides 5V at 200A, the SPRN01N-12 provides 12V at 0.08A, and the SPRN01N-15 provides 15V at 0.07A.
