Mean Well TDR-480-48 Single Output Industrial Power Supply 480W 48V 10A - DIN Rail

metal caseslim size3 phase inputhigh efficiency up to 94.5%built-in active PFC

SKU TDR-480-48

Log in to see price Trade pricing & online ordering for account holders

Select model — 3 in this family

TDR-480-48

TDR-240-48 240W 48V Low stock

TDR-480-48 480W 48V Low stock

TDR-960-48 960W 48V Low stock

Product variants

In stock

Overview

TDR-480-48 is the 48V output model of this series: rated current 10A, rated power 480W, typical efficiency 93%.

TDR-480 is one economical slim 480W DIN rail power supply series, adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 85.5mm in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 3ψ 340VAC to 550VAC (Dual Phase operation possible) and conforms to BS EN/EN61000-3-2, the norm the European Union regulates for harmonic current. TDR-480 is designed with metal housing that enhances the unit's power dissipation. With working efficiency up to 93 %, the entire series can operate at the ambient temperature between -20℃ and 70℃ under air convection. It is equipped with constant current mode for overload protection, fitting various inductive or capacitive applications. The complete protection functions and relevant certificates for industrial control apparatus (UL508, IEC 62368-1 CB approved by UL.) make TDR-480 a very competitive power supply solution for industrial applications.

Features

Three-Phase 340 ~ 550VAC wide range input (Dual phase operation possible)
Width only 85.5mm
Built-in active PFC function compliance to BS EN/EN61000-3-2
High efficiency 93% and low power dissipation
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Built-in constant current limiting circuit
Can be installed on DIN rail TS-35/7.5 or 15
UL508(industrial control equipment)approved
BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level
Optional DC OK relay contact
3 years warranty

Specifications

TDR-480-48Specifications from the official datasheet (2024-11-22 edition)

OUTPUT

DC VOLTAGE: 48V
RATED CURRENT: 10A
CURRENT RANGE: 0 ~ 10A
RATED POWER: 480W
RIPPLE & NOISE (max.)^Note.2: 150mVp-p
VOLTAGE ADJ. RANGE: 48 ~ 55V
VOLTAGE TOLERANCE^Note.3: ±1.0%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±1.0%
SETUP, RISE TIME: 1200ms, 60ms/400VAC 800ms, 60ms/500VAC at full load
HOLD UP TIME (Typ.): 20ms / 400VAC 20ms / 500VAC at full load

INPUT

VOLTAGE RANGE^Note.4: Three-Phase 340 ~ 550VAC (Dual phase operation possible) 480 ~ 780VDC
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF≧0.9/400VAC PF≧0.88/500VAC at full load
EFFICIENCY (Typ.): 93%
AC CURRENT (Typ.): 0.85A/400VAC 0.7A/500VAC
INRUSH CURRENT (Typ.): COLD START 50A
LEAKAGE CURRENT: <3.5mA / 530VAC

PROTECTION

OVERLOAD: 105 ~ 130% rated output power Protection type : Constant current limiting, unit will shut down after 3 sec. ,re-power on to recover
OVER VOLTAGE: 56 ~ 65V Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE: Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP.^Note.5: -30 ~ +70℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 50℃)
VIBRATION: Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6

SAFETY & EMC (Note 4)

SAFETY STANDARDS: UL508, IEC62368-1,UL 62368-1, AS/NZS 62368.1, BIS IS13252(Part1)(only for 24V),EAC TP TC 004 approved, Design refer to BS EN/EN62368-1
WITHSTAND VOLTAGE: I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC O/P-DC OK(optional):0.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:>100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Parameter Standard Test Level

Conducted BS EN/EN55032(CISPR32) / BS EN/EN61204-3 Class B
Radiated BS EN/EN55032(CISPR32) / BS EN/EN61204-3 Class B
Harmonic Current BS EN/EN61000-3-2 Class A
Voltage Flicker BS EN/EN61000-3-3
EMC IMMUNITY: BS EN/EN55035 , BS EN/EN61204-3

Parameter Standard Test Level

ESD BS EN/EN61000-4-2 Level 4, 15KV air; Level 4, 8KV contact
Radiated Field BS EN/EN61000-4-3 Level 3
EFT / Burst BS EN/EN61000-4-4 Level 3
Surge BS EN/EN61000-4-5 Level 4, 2KV / Line-Line, Level 4, 4KV/ Line-Earth
Conducted BS EN/EN61000-4-6 Level 3
Magnetic Field BS EN/EN61000-4-8 Level 4
Voltage Dips and Interruptions BS EN/EN61000-4-11 ＞95% dip 0.5 periods, 30% dip 25 periods＞ 95% interruptions 250 periods

Parameter	Standard	Test Level
Conducted	BS EN/EN55032(CISPR32) / BS EN/EN61204-3	Class B
Radiated	BS EN/EN55032(CISPR32) / BS EN/EN61204-3	Class B
Harmonic Current	BS EN/EN61000-3-2	Class A
Voltage Flicker	BS EN/EN61000-3-3

Parameter	Standard	Test Level
ESD	BS EN/EN61000-4-2	Level 4, 15KV air; Level 4, 8KV contact
Radiated Field	BS EN/EN61000-4-3	Level 3
EFT / Burst	BS EN/EN61000-4-4	Level 3
Surge	BS EN/EN61000-4-5	Level 4, 2KV / Line-Line, Level 4, 4KV/ Line-Earth
Conducted	BS EN/EN61000-4-6	Level 3
Magnetic Field	BS EN/EN61000-4-8	Level 4
Voltage Dips and Interruptions	BS EN/EN61000-4-11	＞95% dip 0.5 periods, 30% dip 25 periods＞ 95% interruptions 250 periods

OTHERS

MTBF: 1174.0K hrs min. Telcordia SR-332(Bellcore) ; 108.3K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 85.5*125.2*128.5mm (W*H*D)
PACKING: 1.51Kg ; 8pcs/13Kg/1.16CUFT

Test conditions and notes7

1. All parameters NOT specially mentioned are measured at 400VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μF & 47μF parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Dual phase operation is allowed under certain derating to output load. Please refer to derating curves for details.
5. Installation clearances : 40mm on top, 20mm on the bottom, 5mm on the left and right side are recommended when loaded permanently with full power. In case the adjacent device is a heat source, 15mm clearance is recommended.
6. The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
7. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

TDR-480-48 Block Diagram — Block Diagram

TDR-480-48 Derating Curve — Derating Curve

TDR-480-48 DC OK Relay Contact (Optional) — DC OK Relay Contact (Optional)

TDR-480-48 Mechanical Specification — Mechanical Specification

TDR-480-48 Installation Instruction — Installation Instruction

Typical applications

Industrial control system
Semiconductor fabrication equipment
Factory automation
Electro-mechanical apparatus

Downloads

Certificates6

Mean Well TDR-480 CB(UL) Certificate PDF Download

Mean Well TDR-480 EMC Certificate PDF Download

Mean Well TDR-480 CE-dec Certificate PDF Download

Mean Well TDR-480 UK-dec Certificate PDF Download

Mean Well E215312-UL Certificate PDF Download

Mean Well EAC Certificate PDF Download

Test reports1

Mean Well TDR-480-48 Test Report PDF Download

Catalogues2

Mean Well Catalog (Industrial) PDF Download

Mean Well DIN RAIL Catalog PDF Download

FAQ

Can I use the TDR-480-48 for a 48V industrial control cabinet?

Yes, if the cabinet uses 48VDC and the total load stays within 10A or 480W. Its 340-550VAC 3 phase input and DIN rail format are aligned with industrial control enclosures that distribute 48VDC from a three-phase source.

Is the TDR-480-48 suitable for 48V building automation or control panels with higher current demand?

It can be used where the panel requires 48VDC with up to 480W and 10A available. The slim metal housing and DIN rail mounting make it practical for cabinet-based control systems that need more capacity than a 240W 48V unit.

Can this model support 48V industrial automation equipment inside a DIN rail enclosure?

Yes, for 48V control and automation loads whose combined requirement does not exceed 10A and 480W. The stated efficiency is up to 93%, and the 128.5 × 125.2 × 85.5 mm form factor is designed for DIN rail cabinet layouts.

Is the TDR-480-48 a better fit than a smaller 48V DIN rail supply when more headroom is needed?

For 48V systems, this unit provides 10A and 480W, compared with 5A and 240W on the TDR-240-48. It keeps the same three-phase 340-550VAC input approach while adding output capacity for larger cabinet loads.

What are the differences between the TDR-480-48 and the other TDR series models?

The TDR-480-48 is 480W at 48V and 10A. The rest of the series includes TDR-240-24 at 240W, 24V, 10A; TDR-240-48 at 240W, 48V, 5A; TDR-480-24 at 480W, 24V, 20A; TDR-960-24 at 960W, 24V, 40A; and TDR-960-48 at 960W, 48V, 20A.

Can the TDR-480-48 be used in enclosed industrial cabinets over a wide temperature range?

The operating temperature range is -30°C to +70°C, which supports use in many indoor control cabinets and enclosures. Since the provided data does not list a separate outdoor or exposed-use enclosure rating, it is better matched to protected cabinet environments.
