Vimar

Vimar Plana Plate 4M Reflex Ash

4 ModuleGrey
SKU VM-14643.40
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

VM-14643.40 is Vimar PLANA 14643.40, plate 4M (2+2) 71mm Reflex ash.

4-module cover plate (2+2, 71 mm distance between centres), technopolymer, Reflex ash

Specifications

VM-14643.40Specifications from the official datasheet

Technical data

Product type
Cover frame for domestic switching devices
Number of units
4
Mounting direction
Horizontal and vertical
Number of device inserts horizontal
4
Number of device inserts vertical
1
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Acrylic glass
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
Grey
RAL-number (similar)
7023
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
151 mm
Height
80 mm
Depth
9.3 mm
Built-in width
151 mm
Built-in height
80 mm

Packaging

EAN
8007352433168
Packed size (cm)
20 × 8 × 0.9
Packed weight
32 g
Pieces per box
5

Certifications

Certifications
CE marking (EU), IMQ (Italy)

Technical drawings

VM-14643.40 Drawings
Drawings

Downloads

FAQ

What is the Vimar Plana Plate 4M Reflex Ash used for?

This model is a cover plate for switch installations in the Vimar Plana series. It is intended for projects where a 4-module plate is needed with a clean, essential appearance. It is suited to commercial and professional interiors that want a refined grey finish.

Which Vimar range is this plate compatible with?

This product belongs to the Vimar Plana range and is identified as a Plana cover plate. For specification and procurement purposes, it should be matched with Plana-series components. The product name and category data both indicate Plana compatibility.

What finish and look does this model have?

The Vimar Plana Plate 4M Reflex Ash comes in a Reflex Ash finish, with the product data listing the colour as grey. Its description emphasizes an essential appearance combined with high performance. That makes it appropriate for projects that want a neutral, modern plate design.

What material style does this cover plate belong to?

This plate is classified under plastic switch material categories. Its product description focuses on a practical, high-performance design offered in multiple colour variants across the material line. For this specific model, the selected finish is Reflex Ash.

What are the warranty period and product weight for this model?

The listed warranty period for SKU VM-14643.40 is 3 years. The product weight is 0.1530 kg. These details can help with project documentation, quoting, and material planning.
