Envo EV-SNP-100-12 LED Driver 100W 12V Waterproof IP67 8.3A

waterproof IP67
SKU EV-SNP-100-12
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →

Select model — 4 in this family

EV-SNP-100-12
In stock
|

Overview

EV-SNP-100-12 is the 12V output model of this series: rated current 0-8.3A, rated power 100W.

EV-SNP-100-12/24 is a constant voltage IP67 LED driver with an input voltage range of 220-240Vac and a conversion efficiency up to 90%. Excellent power factor, low standby power consumption, and comprehensive protection functions not only greatly improve the reliability of the product, but also ensure the product life cycle. This series of products is designed for LED lighting design and applied to outdoor lighting. It is suitable for various application environments in almost all outdoor places where LED luminaires can be installed. Comply with the world's lighting equipment safety regulations

Features

  • AC input(220-240VAC)
  • Built-in active PFC function
  • Compliance to worldwide safety regulations for lighting
  • Protections: Short circuit / Over voltage / Over temperature/Over load
  • Using plastic shell. internal potting.
  • Compliance to worldwide safety

Specifications

EV-SNP-100-12Specifications from the official datasheetDownload datasheet PDF

Output

DC Voltage
12V
Voltage Tolerance
±5%
Rated current
0-8.3A
Rated power
100W

Input

Voltage Range
AC 220V - 240V
Frequency Range
50-60HZ
Power Factor
0.95
Full Load Efficiency (Typ.)
87%
AC Current (Max.)
0.3A/230V
Leakage current
0.7mA 240Vac/60HZ

Protection

Short Circuit
hiccup mode, restart automatically after fault correction
Over load
1.2-1.5 times maximum rated load

Environment

Working TEMP.
-20 - 45°C
Working Humidity
5%RH - 85%RH
Storage TEM.,Humidity
-40°C-80°C; 5%RH-85%RH
TEMP.coefficient
±0.03%/°C (0 ~ 60°C)

Safety&EMC

Safety standards
EN/IEC-61347, EN/IEC-60598 Approved, AS/NZS-61347/60598 Approved
Withstand voltage
Input-Output: 3750V/5mA/1min
Isolation resistance
>5M Ohm/500VDC/25°C/70%RH
EMC EMISSION
Compliance to EN/IEC-55015, EN/IEC-61000, AS CISPR 15:2017
EMC immunity
Compliance to EN-61547:2009, EN-61000-4-2,3,4,5,6,11

Others

Weight
0.48KG
Size
155.6*47.6*32.5mm (L*W*H)
Packing
25PCS

Notes

Warranty
5 years

Technical drawings

EV-SNP-100-12 Mechanical Specification
Mechanical Specification
EV-SNP-100-12 Mechanical Specification (2)
Mechanical Specification (2)
EV-SNP-100-12 Mechanical Drawing
Mechanical Drawing
EV-SNP-100-12 Output load-Temperature curve
Output load-Temperature curve
EV-SNP-100-12 Instruction
Instruction

Downloads

FAQ

What type of applications is the Envo EV-SNP-100-12 designed for?

The Envo EV-SNP-100-12 is a constant-voltage 12V LED driver intended for LED lighting applications that need a 12V DC power source. With a 100W power rating and up to 8.3A output current, it suits commercial and trade buyers sourcing power supplies for compatible 12V LED loads.

What are the key electrical specifications of this LED driver?

This model provides a 12V output with a 100W power rating and a rated current of 8.3A. Its AC input range is listed as 220-240VAC, making it suitable for markets using that mains voltage range.

Is the Envo EV-SNP-100-12 dimmable?

No. The listed dimming control for the EV-SNP-100-12 is none, so it should be treated as a non-dimmable LED driver.

Can this LED driver be used in wet or exposed environments?

This model is described as waterproof with an IP67 rating, which supports use in demanding environments where ingress protection is important. It also uses a plastic shell with internal potting, which helps support durability for protected outdoor or moisture-prone lighting applications.

What protection features does the EV-SNP-100-12 include?

The EV-SNP-100-12 includes short circuit and over load protection. Short circuit protection uses hiccup mode with automatic restart after fault correction, while over load protection activates when the load exceeds 1.2-1.5 times the maximum rated load. These built-in protections are relevant for buyers looking for a robust LED power supply for commercial lighting use.

What operating temperatures is this model rated for?

The specified operating temperature range is -20°C to 45°C. Buyers should confirm that the intended environment stays within that range when selecting this driver for a project.

How does this model compare with lower-power 12V LED drivers?

Compared with lower-wattage 12V drivers, the EV-SNP-100-12 offers up to 100W of output capacity and 8.3A rated current for larger 12V LED loads. It is a better fit when the application requires more output headroom within a 12V constant-voltage product range.

What warranty is offered for the Envo EV-SNP-100-12?

This model is listed with a 5-year warranty period. For trade and project buyers, that can be a useful indicator when evaluating long-term replacement and maintenance expectations.
