Description
Description
Features
AC input 180~264VAC |
Built-in active PFC function |
High efficiency up to 93% |
Forced air cooling by built-in DC fans |
Output voltage/current programmable |
Active current sharing up to 9000W |
Built-in remote ON-OFF control/auxiliary power/power OK signal |
Protections: Short circuit/Overload/Over voltage/Over temperature/Fan failure |
Conformal coating |
5 years warranty |
General Specification
AC input voltage range | 180~264VAC, 254~370VDC |
AC inrush current (max.) | 60A at 230VAC |
Rated Power | 3000W |
Overload protection | 105%~120% |
Over voltage protection | 106%~126% rated output voltage, shut down and repower |
Withstand voltage | I/P - O/P: 3KVAC, I/P - FG: 2KVAC, O/P - FG: 0.5KVAC |
Working temperature | -25~+65°C |
Vibration | 10~500Hz, 5G 10min. /1 cycle, period for 60 min. each along X, Y, Z axes |
Safety standards | UL62368-1, TUV EN62368-1 approved |
EMC standards | EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11 |
Connection | Terminal block for input and output |
Dimension (LxWxH) | 278x 177.8x 63.5 |
Case No. | 902A |
Packing | 4pcs /16kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesCSP Series
-
Power Rating3000 Watt
-
Output Voltage250 Volt
-
Rated Current12 Ampere
-
Input Voltage180V~264V
-
Standards MetCB,CE,DEKRA,EAC,ENEC,FCC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~60°C
-
Warranty5 Year
-
Length27.8 cm
-
Width17.78 cm
-
Height6.35 cm
-
Weight4 kg
