Mean Well

Mean Well DDR-60G-15 DC-DC Converter - 60W - 9~36V in 15V out

2:1 or 4:1 wide input range, fanless design, 4KVdc I/O isolation, ultra slim dimensions
SKU:
DDR-60G-15
Model
Please for Pricing
|

Description

The DDR-60G is a 60W DIN Rail type DC-DC converter with a 52.5mm (3SU) profile, built for demanding industrial power distribution applications. A 4:1 wide input voltage range of 9~36Vdc suits a wide range of DC supply sources, while reinforced 4KVdc I/O isolation ensures clean output. With free air convection cooling, no minimum load requirement, and a broad -40~+85°C operating range, it delivers reliable performance in harsh environments.

Key Features

  • ✓ Compact 52.5mm (3SU) width — DIN rail TS-35/7.5 or 15 compatible
  • ✓ 4:1 wide input voltage range: 9~36Vdc
  • ✓ DC output voltage adjustable ±10%
  • ✓ 4KVdc reinforced I/O isolation
  • ✓ Cooling by free air convection — no minimum load required
  • ✓ Wide operating temperature: -40°C ~ +85°C
  • ✓ Protections: Short circuit / Overload / Over voltage / Reverse polarity / Under voltage lockout
  • ✓ Safety approvals: UL 62368-1, IEC 62368-1, AS/NZS 62368.1, EAC TP TC 004
  • ✓ 3 years warranty

Specifications
  • Brand
    Mean Well
  • Series
    DDR Series
  • Power Rating
    60 Watt
  • Output Voltage
    15 Volt
  • Rated Current
    4 Ampere
  • Input Voltage
    9V~36V
  • Standards Met
    CE,EAC,EMC,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~85°C
  • Warranty
    2 Year
  • Length
    9 cm
  • Width
    5.45 cm
  • Height
    5.25 cm
  • Weight
    0.22 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the DDR-60G-15 to provide a 15V rail for legacy industrial instrumentation from a 24V bus?

Yes. The DDR-60G-15 accepts 9-36V DC input, covering standard 24V industrial DC buses. It outputs 15V at up to 4A (60W), making it suitable for powering older instrumentation, analog signal conditioning modules, and other equipment that requires a 15V supply.

Is the DDR-60G-15 appropriate for powering 15V audio or test equipment in a mobile setup with a 12V battery?

The DDR-60G-15 accepts input as low as 9V DC, so it can operate from a 12V battery even under load sag. It provides a regulated 15V output at up to 4A, which is enough for many bench instruments, audio amplifiers, or measurement devices. Its compact 90 x 54.5 x 52.5 mm size and 0.216 kg weight support portable applications.

Can the DDR-60G-15 power 15V control boards in a vehicle or marine application?

The DDR-60G-15 is well suited for vehicle and marine environments where the supply voltage can range from 12V to 24V nominal. Its 9-36V input range handles voltage fluctuations from cranking, charging, and load dumps. The -40 to +85 degrees C rating and fanless design withstand harsh operating conditions.

Is the DDR-60G-15 rated for use in environments with high humidity or condensation risk?

The DDR-60G-15 does not carry an IP ingress protection rating, so it should not be exposed directly to moisture or condensation. For humid environments, install it inside a sealed enclosure rated to IP65 or higher. The unit itself operates from -40 to +85 degrees Celsius, so temperature is not typically the limiting factor.

What other output voltages are available in the DDR-60G series?

The DDR-60G series (9-36V input) comes in four output variants: DDR-60G-5 at 54W/5V/10.8A, DDR-60G-12 at 60W/12V/5A, DDR-60G-15 at 60W/15V/4A, and DDR-60G-24 at 60W/24V/2.5A. For a higher input range of 18-75V, the DDR-60L series offers the same output voltage options.
