Mean Well

Mean Well DDR-60G-24 DC-DC Converter - 60W - 9~36V in 24V out

2:1 or 4:1 wide input range, fanless design, 4KVdc I/O isolation, ultra slim dimensions
SKU:
DDR-60G-24
Model
Please for Pricing
|

Description

The DDR-60G is a 60W DIN Rail type DC-DC converter with a 52.5mm (3SU) profile, built for demanding industrial power distribution applications. A 4:1 wide input voltage range of 9~36Vdc suits a wide range of DC supply sources, while reinforced 4KVdc I/O isolation ensures clean output. With free air convection cooling, no minimum load requirement, and a broad -40~+85°C operating range, it delivers reliable performance in harsh environments.

Key Features

  • ✓ Compact 52.5mm (3SU) width — DIN rail TS-35/7.5 or 15 compatible
  • ✓ 4:1 wide input voltage range: 9~36Vdc
  • ✓ DC output voltage adjustable ±10%
  • ✓ 4KVdc reinforced I/O isolation
  • ✓ Cooling by free air convection — no minimum load required
  • ✓ Wide operating temperature: -40°C ~ +85°C
  • ✓ Protections: Short circuit / Overload / Over voltage / Reverse polarity / Under voltage lockout
  • ✓ Safety approvals: UL 62368-1, IEC 62368-1, AS/NZS 62368.1, EAC TP TC 004
  • ✓ 3 years warranty

Specifications
  • Brand
    Mean Well
  • Series
    DDR Series
  • Power Rating
    60 Watt
  • Output Voltage
    24 Volt
  • Rated Current
    2.5 Ampere
  • Input Voltage
    9V~36V
  • Standards Met
    CE,EAC,EMC,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~85°C
  • Warranty
    2 Year
  • Length
    9 cm
  • Width
    5.45 cm
  • Height
    5.25 cm
  • Weight
    0.22 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the DDR-60G-24 to step up a 12V battery system to 24V for industrial sensors?

Yes. The DDR-60G-24 accepts 9-36V DC input, so it can boost a 12V battery source to a regulated 24V output at up to 2.5A (60W). This is useful for powering 24V industrial sensors, small PLCs, and communication modules from a 12V battery bank in remote or mobile installations.

Is the DDR-60G-24 suitable for converting a 24V solar charge controller output to a clean 24V rail?

The DDR-60G-24 accepts 9-36V and outputs a regulated 24V at 2.5A. Even though the input and output are both nominally 24V, the converter provides isolation and regulation that protects sensitive 24V loads from voltage fluctuations on the solar bus. The 4KVdc isolation is particularly valuable for separating solar and load ground references.

Can the DDR-60G-24 power a 24V DIN rail gateway or edge computing device in a small control panel?

Yes. At 60W and 24V/2.5A, the DDR-60G-24 can power compact IoT gateways, edge controllers, and protocol converters. Its small 90 x 54.5 x 52.5 mm footprint and DIN rail mounting fit easily in space-constrained panels, and the fanless design eliminates maintenance concerns from dust buildup.

Can I install the DDR-60G-24 in a freezer room or cold storage facility?

The DDR-60G-24 is rated for operation from -40 to +85 degrees Celsius, so it handles cold storage and freezer environments without any issues. It should still be protected from direct contact with water or ice, as it does not carry an IP ingress protection rating.

How does the 60W DDR-60G-24 compare to higher-wattage 24V options in the DDR series?

The DDR series offers 24V output at multiple power levels for the 9-36V input range: the DDR-15G-24 at 15W/0.63A, DDR-30G-24 at 30W/1.25A, and DDR-60G-24 at 60W/2.5A. For loads exceeding 60W, the DDR-120 series (99.6-120W) and DDR-240 series (240W) provide more headroom with different input range options.
