Mean Well

Mean Well EPP-100-27 Power Supply 75W 27V

4" x 2", high efficiency up to 92%, economical PFC, no load power consumption
SKU:
EPP-100-27
End of Life, Succeeded by LOP-200-27
Please for Pricing
|

Description

Features

4"x2" compact size
Universal AC input / Full range
Built-in active PFC function
High efficiency up to 92.5%
Protections: Short circuit/Overload/Over voltage/Over temperature
75W free air convection, 100W with 20CFM forced air
LED indicator for power on
No-load power consumption<0.5W
Built-in 12V/0.3A auxiliary output
3 years warranty

General Specification

AC input voltage range 90~264VAC; 127~370VDC
AC inrush current Cold start 70A/230VAC
Leakage current

<2mA/264VAC
Overload protection 105 ~ 145% rated output power
Over-voltage protection 110%~130% rated output voltage
Setup, rise, hold up time 1000ms, 30ms, 16ms
Withstand voltage I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC
Working temperature -30~+70°C
Vibration 10~500Hz, 2G 10min./1 cycle, the period for 60min. Each along X, Y, Z axes
Safety standards UL,TUV BS EN62368-1
EMC standards UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved
Connection I/P: 3 Pin JST B3P-VH, O/P: 4 Pin JST B4P-VH
Dimension (LxWxH) 101.6x50.8x29
Packing 72pcs / 15.4kg

Specifications
  • Brand
    Mean Well
  • Series
    EPP Series
  • Power Rating
    75.6 Watt
  • Output Voltage
    27 Volt
  • Rated Current
    2.8 Ampere
  • Input Voltage
    90V~264V
  • Standards Met
    CB,CE,EAC,TUV,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -30°C~70°C
  • Warranty
    3 Year
  • Length
    10.16 cm
  • Width
    5.08 cm
  • Height
    2.9 cm
  • Weight
    0.2 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the EPP-100-27 for 27V industrial control or test equipment?

Yes, this model is a constant-voltage 27V supply rated for 2.8A and 75.6W. It fits industrial or embedded equipment that specifically requires 27V DC and stays within that 2.8A and 75.6W output limit.

Is the EPP-100-27 suitable for a 27V automation panel subsystem?

It can be used for a 27V automation subsystem when the connected load needs constant-voltage 27V power and draws no more than 2.8A. The wide 90-264VAC input also helps when the equipment is deployed across facilities with different AC supply standards.

Can this 27V power supply run embedded electronics that need stable DC output?

Yes, the EPP-100-27 is designed for constant-voltage output at 27V with up to 75.6W available. That makes it appropriate for embedded electronics, instruments, or control assemblies that are designed for 27V DC and need 2.8A or less.

Is the EPP-100-27 meant for outdoor or exposed environments?

This unit has an operating temperature range of -30°C to +70°C, but no IP rating is listed in the specs. That points to use inside protected equipment or an enclosure rather than direct outdoor or washdown exposure.

How does the EPP-100-27 compare with the other 27V models in the EPP series?

Within the 27V group, the EPP-100-27 is rated at 75.6W and 2.8A, the EPP-120S-27 is 119.9W and 4.44A, the EPP-150-27 is 100.17W and 3.71A, the EPP-200-27 is 143.1W and 5.3A, the EPP-300-27 is 199.8W and 7.4A, the EPP-400-27 is 251.1W and 9.3A, and the EPP-500-27 is 321.3W and 11.9A. The main differences are output power and available current at the same 27V output.
