Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well HLG-185H-54AWE Power Supply 185W 54V 3.45A

4.9 (21 reviews)

premium quality7 years warrantyaluminium casinghigh efficiency

SKU:

HLG-185H-54AWE

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The HLG-185H is a 185W Mean Well power converter (input range: 90~305VAC, operating temperature: -40~+90℃).

Key Features

✓ Input voltage range: 90~305VAC
✓ DC output voltage adjustable ±10%
✓ 3.75KVAC reinforced I/O isolation
✓ Cooling by free air convection
✓ Wide operating temperature: -40~+90℃
✓ Protections: Short circuit / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: EN/AS/NZS
✓ 3 years warranty

Frequently Asked Questions

Can I use the HLG-185H-54AWE to power 54V LED strips in fully exposed outdoor locations?

Yes. The HLG-185H-54AWE outputs 54V at up to 3.45A (185W) with an IP67 waterproof rating, so it can be mounted outdoors in direct rain, sprinkler zones, or coastal environments. The aluminium casing and -40°C to +90°C range handle extreme weather.

Is the HLG-185H-54AWE suitable for outdoor 54V LED signage or building facade lighting?

Yes. With 185W at 54V and IP67 waterproofing, it can power 54V LED sign modules, facade wash lights, or architectural accent fixtures mounted directly on exterior walls. The wide 90-305VAC input handles varying mains voltages across different regions.

Can the HLG-185H-54AWE drive 54V LED fixtures in harsh industrial outdoor environments?

Yes. The IP67 rating makes it dust-tight and submersion-resistant, while the -40°C to +90°C operating range covers freezing winters and rooftop-hot summers. It is well suited for loading docks, outdoor production areas, or equipment yards running 54V LED fixtures.

What distinguishes the HLG-185H-54AWE from the standard HLG-185H-54?

Both the HLG-185H-54AWE and the HLG-185H-54 share the same 185W / 54V / 3.45A output, IP67 waterproof rating, and identical 228 x 68 x 38.8 mm dimensions. The AWE suffix indicates a variant with additional regional certifications or compliance features, making it suited for specific markets or project specifications that require them.

How many meters of 54V LED strip can the HLG-185H-54AWE power?

Divide 185W by your strip's rated power per meter. For example, a 54V strip drawing 15W/m could run about 12.3 meters (185W / 15W per meter). Always check your strip's rated power per meter and keep total load at or below 185W.

Can the HLG-185H-54AWE withstand installation in wet underground vaults or flood-prone areas?

Its IP67 rating protects against temporary submersion up to 1 meter depth, so it handles brief flooding in light wells, underground vaults, or low-lying junction boxes. Combined with the -40°C to +90°C operating range, it covers most real-world harsh and wet installation scenarios.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well HLG-185H-48 Power Supply 185W 48V 3.9A	185W	48V	3.9A	IP67	View
Mean Well S-HLG-185H-24 Power Supply 185W 24V with AU/NZ plug 7.8A	185W	24V	7.8A	IP67	View
Mean Well HLG-185H-48B Power Supply 185W 48V- Dimmable 3.9A	185W	48V	3.9A	IP67	View
Mean Well HLG-185H-36B Power Supply 185W 36V- Dimmable 5.2A	185W	36V	5.2A	IP67	View
