Mean Well HLG-80H-C350A Power Supply 89.95W 350mA - Adjustable

Yes. The HLG-80H-C350A delivers 350mA constant current with a CC voltage range of 128-257V, making it well suited for long series strings of LEDs used in channel letters or large sign modules. The high output voltage range allows you to connect many LEDs in series, and the adjustable output lets you fine-tune the current for optimal brightness.

Yes. This driver provides 350mA constant current at up to 89.95W across a 128-257V CC range. It works well with high-voltage COB LED downlight modules or series-connected downlight strings whose total forward voltage falls within that window. The adjustable output helps match the driver to your exact fixture requirements.

Yes. With 350mA constant current and a CC voltage range of 128-257V, this driver can handle lengthy series LED strings used in cove lighting, facade illumination, or linear architectural fixtures. The IP65 rating allows installation in sheltered outdoor or damp indoor locations.

The number of LEDs depends on each LED's forward voltage. The HLG-80H-C350A operates at 350mA constant current with a CC voltage range of 128-257V and a maximum power of 89.95W. Add the forward voltages of your LEDs in series and verify the total falls between 128V and 257V.

Yes. It is rated for operating temperatures from -40°C to +80°C, so it handles freezing warehouses, outdoor canopies in winter, and warm enclosed ceiling cavities. The IP65 rating and aluminium casing provide additional protection against moisture and dust.

All three share the same 89.95W, 350mA constant current output and IP65 enclosure. The C350A (this model) has an adjustable output via potentiometer but no external dimming input. The C350AB adds both potentiometer adjustment and 1-10V/PWM dimming. The C350B includes the dimming input only. Note the C350B has a narrower CC voltage range of 167-257V compared to 128-257V for the A and AB variants.
