Mean Well HLG-80H-C350B Power Supply 89.95W 350mA - Dimmable

Yes. The HLG-80H-C350B delivers 350mA constant current across a CC voltage range of 167-257V, supporting long series strings for commercial signage. The B suffix provides a dimming input for 1-10V, PWM, or resistance control, letting you adjust sign brightness based on time of day or ambient conditions.

Yes. At 350mA and up to 89.95W, this driver can power linear LED arrays for cove, facade, or accent lighting where the total string voltage falls between 167V and 257V. The dimming input allows smooth brightness transitions for scene control.

Yes. This driver provides 350mA constant current within a 167-257V CC range, which suits high-voltage COB downlight modules. The built-in dimming interface accepts 1-10V, PWM, or resistance signals for adjusting light output without additional hardware.

The HLG-80H-C350B has a CC voltage range of 167-257V, which is narrower at the low end than the C350A and C350AB variants that both start at 128V. All three models share the same 89.95W maximum power and 350mA constant current output. Choose the B model when you need dimming and your LED string voltage will remain above 167V.

The exact count depends on each LED's forward voltage. The HLG-80H-C350B runs at 350mA constant current with a CC voltage range of 167-257V. Add up the forward voltages of your LEDs in series and confirm the total stays within that range. Maximum power output is 89.95W.

Yes. The HLG-80H-C350B has an IP65 water-resistant rating, which means it is fully protected against dust ingress and can withstand low-pressure water jets from any direction. It operates from -40°C to +80°C, making it suitable for sheltered outdoor locations and harsh indoor environments.
