Mean Well HRP-150N3-12 Power Supply 156W 12V, 300% peak power model...
Please Login for Pricing
Description
Description
The HRP-150N3 is a 150W Mean Well DIN rail power converter with a 159mm profile (input range: 85~264VAC).
Key Features
- ✓ 159mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 85~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: AS/NZS 62368.1
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesHRP Series
-
Power Rating150 Watt
-
Output Voltage12 Volt
-
Rated Current13 Ampere
-
Input Voltage85V~264V
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~70°C
-
Warranty5 Year
-
Length15.9 cm
-
Width9.7 cm
-
Height3.8 cm
-
Weight0.54 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the Mean Well HRP-150N3-12 designed for?
The HRP-150N3-12 is an enclosed AC/DC power supply designed for industrial and high-reliability applications that need a regulated 12V output. It is rated at 156W and is part of Mean Well's HRP series with 300% peak power capability for short-duration demand.
What are the main electrical ratings of the HRP-150N3-12?
This model provides a 12V DC output with a rated current of 13A. It is listed with a 150W class power rating and a 156W product description, and it supports output voltage adjustment of approximately plus or minus 15%.
Does the HRP-150N3-12 support high peak loads?
Yes. A key feature of this model is its 300% peak power capability, which helps it handle short-term high-demand loads better than a standard supply of similar nominal wattage. It also includes a built-in constant current limiting circuit to support demanding operating conditions.
What input range does the HRP-150N3-12 accept?
The HRP-150N3-12 accepts a universal AC input range of 85 to 264VAC and also supports 120 to 370VDC input. It is also specified to withstand a 300VAC surge input for 5 seconds.
Is the HRP-150N3-12 suitable for harsh industrial environments?
Yes. This model is rated for operation from -40°C to +70°C, supports operating altitude up to 5000 meters, and withstands 5G vibration. Its EMC listing also includes heavy industry level compliance under EN61000-6-2.
What protection features are built into the HRP-150N3-12?
The power supply includes protection for short circuit, overload, over voltage, and over temperature. Its overload protection range is 105% to 135%, and the unit shuts down output voltage after sustained overload before recovery by re-powering.
What approvals and physical size does the HRP-150N3-12 have?
The HRP-150N3-12 is approved to UL62368-1, TUV EN62368-1, and AS/NZS 62368.1 safety standards. Its compact 1U low-profile enclosure measures 159 x 97 x 38 mm and weighs approximately 0.54 kg.
What warranty comes with the HRP-150N3-12?
This model includes a 5-year warranty from Mean Well. That warranty period is consistent with the product's positioning for industrial and high-reliability use.
