Over 15 years experience of providing support of MEAN WELL Power Supplies
Description
Description
Features
180~305VAC input only |
Fully encapsulated with IP67 level |
Protections: Short circuit / Overload / Over voltage / Over temperature |
Constant voltage design (C.V. mode) |
Class 2 power unit |
Isolation class II, no F.G. |
Withstand 300VAC surge input for 5 seconds |
Cooling by free air convection |
100% full load burn-in test |
Low cost, high reliability |
Suitable for LED-based decorative/architectural lighting, LED stage and theater lighting, and LED electronic displays |
2 years warranty |
General Specification
AC input voltage range | 180~305VAC; 254~431VDC |
AC inrush current | Cold start, 60A at 230VAC |
Overload protection | 110%~150% hiccup mode, auto-recovery |
Over voltage protection | 115%~135% rated output voltage |
Withstand voltage | I/P-O/P: 3kVAC |
Working temperature | -25~+70°C (refer to output derating curve) |
Vibration | 10~500Hz, 2G 10 minutes /1 cycle, period for 60 minutes each along X, Y, Z axes |
Safety standards | Design refer to IEC60950-1 |
EMC standards | EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11 |
Connection Input | UL rated, SJTW 18AWGx2C (30cm) |
Connection Output | UL rated, SJTW 14AWGx2C (30cm) |
Dimension (LxWxH)(mm) | 191x 63x 37.5 |
Specifications
Specifications
-
BrandMean Well
-
SeriesLP Series
-
Power Rating120 Watt
-
Output Voltage15 Volt
-
Rated Current8 Ampere
-
Input Voltage180V~305V
-
Standards MetCE,EAC,FCC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~65°C
-
Warranty2 Year
-
Length19.1 cm
-
Width6.3 cm
-
Height3.75 cm
-
Weight0.74 kg
File Downloads
File Downloads
::specification::
