Mean Well

Mean Well LPV-60-48 LED Driver — 60W 48V 1.25A IP67 Waterproof

Constant Voltage, CB/CE/EAC/UL Certified, 90-264VAC Universal Input, 2-Year Warranty
SKU:
LPV-60-48
Model
Please for Pricing
|

Description

Mean Well LPV-60-48 LED Driver — 60W 48V 1.25A IP67 Waterproof

The Mean Well LPV-60-48 is a 60W, 48V constant voltage LED driver with IP67 waterproof protection, engineered for reliable performance in demanding indoor and outdoor LED lighting applications. Built to Mean Well's industry-leading quality standards, it delivers stable 48V DC output at up to 1.25A and carries CB, CE, EAC, UL certifications for global compliance.

Accepting 90-264VAC universal AC input, the LPV-60-48 operates reliably across a wide supply range. It features built-in short circuit, overload, and over-voltage protection to safeguard connected LED loads, and is rated for operation from -30°C to +70°C making it suitable for outdoor and harsh-environment installations.

Key Features

  • Constant voltage output: 48V DC at up to 1.25A (60W max)
  • IP67 waterproof and dustproof — suitable for outdoor installations
  • Universal AC input: 90-264VAC
  • Certifications: CB, CE, EAC, UL
  • Wide operating temperature: -30°C to +70°C
  • Built-in protections: short circuit, overload, over-voltage
  • Compact, lightweight enclosure: 162.5 × 42.5 × 32.0 mm, 0.4 kg
  • 2-year Mean Well warranty

Specifications

Model LPV-60-48
Output Power 60W
Output Voltage 48V DC
Output Current 1.25A
Operation Mode Constant Voltage
Input Voltage Range 90-264VAC
IP Rating IP67 Waterproof
Certifications CB, CE, EAC, UL
Operating Temperature -30°C to +70°C
Dimensions (L × W × H) 162.5 × 42.5 × 32.0 mm
Weight 0.4 kg
Warranty 2 Years

Applications

  • LED signage and electronic displays
  • Architectural and decorative LED lighting
  • Outdoor and landscape LED installations
  • Stage and theater LED lighting
  • Commercial LED lighting installations

Specifications
  • Brand
    Mean Well
  • Series
    LP Series
  • Power Rating
    60 Watt
  • Output Voltage
    48 Volt
  • Rated Current
    1.25 Ampere
  • Input Voltage
    90V~264V
  • Standards Met
    CB,CE,EAC,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -30°C~70°C
  • Warranty
    2 Year
  • Length
    16.25 cm
  • Width
    4.25 cm
  • Height
    3.2 cm
  • Weight
    0.4 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What types of LED lighting can the LPV-60-48 power?

The LPV-60-48 is suited for 48V LED strip systems, architectural lighting, and commercial signage that operates at 48V. At 60W maximum output, it can drive a 48V LED load up to 60W — check your strip's rated power per meter to calculate the maximum run length. Its IP67 rating makes it a practical choice for outdoor signage or covered exterior installations.

How much LED strip can I run from the LPV-60-48?

The LPV-60-48 delivers up to 60W at 48V. To find the maximum strip length, divide 60W by your strip's rated wattage per meter — for example, a 10W/m strip would allow up to 6 meters. Always check your strip's rated power per meter, as actual limits depend on that specification.

Is the LPV-60-48 suitable for outdoor or wet environments?

Yes. The LPV-60-48 carries an IP67 rating, meaning it is dust-tight and protected against temporary immersion in water up to 1 meter. It operates across a temperature range of -30°C to +70°C, making it appropriate for outdoor LED signage and lighting installations exposed to rain or humidity.

What input voltage range does the LPV-60-48 accept?

The LPV-60-48 accepts a universal input range of 90–264VAC, so it works with standard electrical supplies in North America, Europe, and most other regions without any manual switching. This makes it convenient for projects that may be deployed across different countries or buildings with variable mains voltage.

What certifications does the LPV-60-48 hold?

The LPV-60-48 is certified to CB, CE, EAC, and UL standards. These certifications cover major markets including the United States (UL), Europe (CE), and the Eurasian Economic Union (EAC), and the CB mark supports acceptance in many additional countries. It also carries a 2-year warranty from Mean Well.
