Mean Well MPS-120-48 Power Supply 120W 48V he rated current is based on there being a fan that can provide 25CFM. 2.5A

SKU MPS-120-48
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
End of Life, Succeeded by RPS-120-48
Available to order
|

Overview

MPS-120-48 is the 48V output model of this series: rated current 2.5A, typical efficiency 82%.

Specifications

MPS-120-48Specifications from the official datasheet (2013-08-16 edition)Download datasheet PDF

Output Chart

OUTPUT VOLTAGE
48V
RATED CURRENT
2.5A
OUTPUT CURRENT MINIMUM LOAD
0A
OUTPUT CURRENT CONVECTION (max.)
1.7A
OUTPUT CURRENT WITH FAN WITH 25CFM FAN (Note 2)Note 2
2.5A
OUTPUT CURRENT PEAK LOAD WITH 25CFM FAN (Max.) (Note 4)Note 4
2.8A
RIPPLE & NOISE (Max.) (Note 2)Note 2
120mVp-p
VOLTAGE TOLERANCE (Note 3)Note 3
±2.0%
LINE REGULATION
±1.0%
LOAD REGULATION
±2.0%
EFFICIENCY
82%

Specification

AC INPUT VOLTAGE
90~264VAC, 47~440Hz / 127~370VDC
AC INPUT CURRENT (Typ.)
Maximum input current 2.9A at 115VAC, 60Hz or 1.7A at 230VAC, 60Hz with 100% output load
INRUSH CURRENT (Typ.)
Less than 22A at 115VAC or less than 50A at 230VAC under cold start conditions; limited by internal thermistors
SETUP, RISE TIME
800ms, 20ms / 230VAC at full load; 2000ms, 50ms / 115VAC at full load
HOLD-UP TIME (Typ.)
80ms / 230VAC at full load; 14ms / 115VAC at full load
LEAKAGE CURRENT (Note 7)Note 7
Earth leakage current < 150μA/264VAC, Touch current < 100μA/264VAC
DC OUTPUT ADJ. RANGE
-5%~+10% rated output voltage, adjustable by potential meter
OVERLOAD PROTECTION
Protected against short circuit and overload; hiccup mode at 120~160% rated load (MPS-120), recovers automatically after fault condition is removed
OVER VOLTAGE PROTECTION
120%~140% rated output voltage, shut down
POWER GOOD / FAIL SIGNAL (OPTIONAL)
TTL high for power good, TTL low for power fail; +5V TTL signal sent 10~500ms after output reaches 90% of rated value; goes low at least 1ms before output drops below 90%
WORKING TEMP.
-20~70℃ (refer to derating curves)
WORKING HUMIDITY
20~90% RH non-condensing
STORAGE TEMP., HUMIDITY
-40~+85℃, 10~90% RH
TEMP. COEFFICIENT
±0.04%/℃ on all outputs at full load (0~50℃)
VIBRATION
2G, 10Hz~500Hz, 10-minute cycle; 6 testing cycles (60 minutes) each along X, Y, Z axes
SAFETY STANDARDS
Medical: UL60601-1, TUV EN60601-1, IEC60601-1 approved; Commercial: also designed referring to UL60950-1, TUV EN60950-1
WITHSTAND VOLTAGE
I/P-O/P:4000VAC, I/P-FG:2000VAC, O/P-FG:500VAC
ISOLATION RESISTANCE
>100M Ohms for I/P-O/P, I/P-FG, O/P-FG at 500VDC
EMI COMPLIANCE
Conducted & Radiation: EN55011 Class B, EN55022 Class B; Harmonic distortion: EN61000-3-2; Voltage flicker: EN61000-3-3
EMS COMPLIANCE
ESD air: EN61000-4-2 Level 3, 8KV; ESD contact: EN61000-4-2 Level 2, 4KV; RF field susceptibility: EN61000-4-3 Level 2, 3V/m, Level 3, 10V/m; EFT/Burst: EN61000-4-4 Level 2, 1KV/5KHz, Level 3, 2KV/5KHz; Lightning/Surge: EN61000-4-5 Level 2, 2KV/Line-Line, Level 4, 4KV/Line-Earth; Conducted RF susceptibility: EN61000-4-6 Level 2, 3Vrms/m, Level 3, 10Vrms/m; Magnetic field immunity: EN61000-4-8 Level 2, 3A/m, Level 3, 10A/m; Voltage dip, interruption: EN61000-4-11 compliance; Digital phone carrier immunity: ENV50204 Level 2, 3V/m, 900MHz, Level 3, 10A/m, 900MHz
MTBF
262,100 hours min. at full load and 25℃ of ambient temperature, MIL-HDBK-217F
DIMENSION (L*W*H)
177.8x107.95x35.5mm or 7"x4.25"x1.4"
PACKING
0.55Kg; 24pcs/14.5Kg/0.99CUFT
Test conditions and notes7
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μf & 47μf parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. 33% Duty cycle maximum within every 30 seconds. Average output power should not exceed the rated power.
  5. 5. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to "EMI testing of component power supplies." (as available on http://www.meanwell.com)
  6. 6. Heat Sink HS1,HS2 can not be shorted.
  7. 7. Touch current was measured from primary input to DC output.

Technical drawings

MPS-120-48 1 2 0 W M e d i c a l series
1 2 0 W M e d i c a l series

Downloads

FAQ

Can I use the MPS-120-48 for 48V industrial sensors or control devices?

Yes, it provides a constant 48V output up to 2.5A and 120W with a 25CFM fan, or 1.7A with convection cooling. It is suited to 48V industrial or automation equipment that requires a fixed 48V DC source and stays within those limits.

Is this a good fit for 48V telecom or network hardware that needs DC power?

It can be used for 48V DC equipment when the load does not exceed 2.5A or 120W with a 25CFM fan (1.7A by convection). Buyers should match the equipment's required voltage exactly to 48V, since this is a constant-voltage model.

Can the MPS-120-48 power a 48V automation subsystem inside a machine enclosure?

Yes, the 48V constant-voltage output and 120W rating (with a 25CFM fan; 1.7A by convection) make it appropriate for enclosed automation subsystems that run on 48V DC. Its input range of 90-264VAC also supports operation from a wide AC mains range.

Is this power supply intended for outdoor use?

The listed operating temperature is -20°C to +70°C (with derating per the derating curves), but no IP rating is provided in the specs. Based on the supplied data, temperature capability is defined, while exposure to rain, dust, or hose-down conditions is not.

What are the 48V options in the MPS series and where does this model fit?

On this spec sheet the MPS-120-48 is the only 48V model of the 120W medical series, rated 120W at 2.5A with a 25CFM fan or 1.7A by convection. The other single-output MPS-120 models are 3.3V, 5V, 12V, 15V and 24V.
