Mean Well MPS-120-5 Power Supply 110W 5V he rated current is based on there being a fan that can provide 25CFM. 22A

SKU MPS-120-5
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
End of Life, Succeeded by RPS-120-5
Available to order
|

Overview

MPS-120-5 is the 5V output model of this series: rated current 22A, typical efficiency 73%.

Specifications

MPS-120-5Specifications from the official datasheet (2013-08-16 edition)Download datasheet PDF

Output Chart

OUTPUT VOLTAGE
5V
RATED CURRENT
22A
OUTPUT CURRENT MINIMUM LOAD
0A
OUTPUT CURRENT CONVECTION (max.)
14.7A
OUTPUT CURRENT WITH FAN WITH 25CFM FAN (Note 2)Note 2
22A
OUTPUT CURRENT PEAK LOAD WITH 25CFM FAN (Max.) (Note 4)Note 4
26A
RIPPLE & NOISE (Max.) (Note 2)Note 2
80mVp-p
VOLTAGE TOLERANCE (Note 3)Note 3
±3.0%
LINE REGULATION
±1.0%
LOAD REGULATION
±3.0%
EFFICIENCY
73%

Specification

AC INPUT VOLTAGE
90~264VAC, 47~440Hz / 127~370VDC
AC INPUT CURRENT (Typ.)
Maximum input current 2.9A at 115VAC, 60Hz or 1.7A at 230VAC, 60Hz with 100% output load
INRUSH CURRENT (Typ.)
Less than 22A at 115VAC or less than 50A at 230VAC under cold start conditions; limited by internal thermistors
SETUP, RISE TIME
800ms, 20ms / 230VAC at full load; 2000ms, 50ms / 115VAC at full load
HOLD-UP TIME (Typ.)
80ms / 230VAC at full load; 14ms / 115VAC at full load
LEAKAGE CURRENT (Note 7)Note 7
Earth leakage current < 150μA/264VAC, Touch current < 100μA/264VAC
DC OUTPUT ADJ. RANGE
-5%~+10% rated output voltage, adjustable by potential meter
OVERLOAD PROTECTION
Protected against short circuit and overload; hiccup mode at 120~160% rated load (MPS-120), recovers automatically after fault condition is removed
OVER VOLTAGE PROTECTION
115%~135% rated output voltage, shut down
POWER GOOD / FAIL SIGNAL (OPTIONAL)
TTL high for power good, TTL low for power fail; +5V TTL signal sent 10~500ms after output reaches 90% of rated value; goes low at least 1ms before output drops below 90%
WORKING TEMP.
-20~70℃ (refer to derating curves)
WORKING HUMIDITY
20~90% RH non-condensing
STORAGE TEMP., HUMIDITY
-40~+85℃, 10~90% RH
TEMP. COEFFICIENT
±0.04%/℃ on all outputs at full load (0~50℃)
VIBRATION
2G, 10Hz~500Hz, 10-minute cycle; 6 testing cycles (60 minutes) each along X, Y, Z axes
SAFETY STANDARDS
Medical: UL60601-1, TUV EN60601-1, IEC60601-1 approved; Commercial: also designed referring to UL60950-1, TUV EN60950-1
WITHSTAND VOLTAGE
I/P-O/P:4000VAC, I/P-FG:2000VAC, O/P-FG:500VAC
ISOLATION RESISTANCE
>100M Ohms for I/P-O/P, I/P-FG, O/P-FG at 500VDC
EMI COMPLIANCE
Conducted & Radiation: EN55011 Class B, EN55022 Class B; Harmonic distortion: EN61000-3-2; Voltage flicker: EN61000-3-3
EMS COMPLIANCE
ESD air: EN61000-4-2 Level 3, 8KV; ESD contact: EN61000-4-2 Level 2, 4KV; RF field susceptibility: EN61000-4-3 Level 2, 3V/m, Level 3, 10V/m; EFT/Burst: EN61000-4-4 Level 2, 1KV/5KHz, Level 3, 2KV/5KHz; Lightning/Surge: EN61000-4-5 Level 2, 2KV/Line-Line, Level 4, 4KV/Line-Earth; Conducted RF susceptibility: EN61000-4-6 Level 2, 3Vrms/m, Level 3, 10Vrms/m; Magnetic field immunity: EN61000-4-8 Level 2, 3A/m, Level 3, 10A/m; Voltage dip, interruption: EN61000-4-11 compliance; Digital phone carrier immunity: ENV50204 Level 2, 3V/m, 900MHz, Level 3, 10A/m, 900MHz
MTBF
262,100 hours min. at full load and 25℃ of ambient temperature, MIL-HDBK-217F
DIMENSION (L*W*H)
177.8x107.95x35.5mm or 7"x4.25"x1.4"
PACKING
0.55Kg; 24pcs/14.5Kg/0.99CUFT
Test conditions and notes7
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μf & 47μf parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. 33% Duty cycle maximum within every 30 seconds. Average output power should not exceed the rated power.
  5. 5. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to "EMI testing of component power supplies." (as available on http://www.meanwell.com)
  6. 6. Heat Sink HS1,HS2 can not be shorted.
  7. 7. Touch current was measured from primary input to DC output.

Technical drawings

MPS-120-5 1 2 0 W M e d i c a l series
1 2 0 W M e d i c a l series

Downloads

FAQ

Can I use the MPS-120-5 for a 5V PLC accessory or industrial logic load?

Yes, it supplies a constant 5V output up to 22A (110W) with a 25CFM fan, or up to 14.7A with convection cooling. That makes it suitable for 5V industrial logic assemblies, controller accessories, and other 5V DC loads that need higher current capacity.

Is this power supply appropriate for 5V embedded computing or single-board systems?

It can be a fit for 5V embedded systems when the total demand stays within 14.7A with convection cooling, or 22A and 110W with a 25CFM fan. The constant-voltage design is intended for loads that require a fixed 5V DC source rather than a constant-current output.

Can the MPS-120-5 support a bank of 5V automation electronics in one enclosure?

Yes, its 22A output capacity with a 25CFM fan (14.7A by convection) is useful where several 5V automation or control loads share one power source. The 90-264VAC input range also supports operation across common global AC input ranges.

Is the MPS-120-5 suitable for harsh indoor or outdoor conditions?

The provided specifications give an operating temperature range of -20°C to +70°C (with derating per the derating curves), but they do not list an IP rating. That supports temperature evaluation, but it does not confirm suitability for outdoor, wet, or dust-exposed environments.

How does this compare with the other 5V MPS power supplies?

On this spec sheet the MPS-120-5 is the only single-output 5V model of the 120W medical series; the other MPS-120 models are 3.3V, 12V, 15V, 24V and 48V. The multi-output MPD-120, MPT-120 and MPQ-120 models also carry a 5V output rated 10A alongside their other outputs.
