Over 15 years experience of providing support of MEAN WELL Power Supplies
Description
Description
Features
Universal AC input / Full range |
Fully isolated plastic case with screw terminal style of I/O |
Built-in constant current limiting circuit (C.V.+C.C. mode) |
Adjustable output voltage and current level |
Built-in active PFC function, PF>0.9 for 75% of load or higher |
High efficiency up to 89% |
Class 2 power unit / Pass LPS |
Isolation class II, no F.G. for PLC-30 |
Cooling by free air convection |
Protections: Short circuit / Over current / Over voltage / Over temperature |
100% full load burn-in test |
Suitable for LED lighting and moving sign applications |
2 years warranty |
General Specification
AC input voltage range | 90~305VAC ; 127~431VDC |
AC inrush current (max.) | Cold start, 35A at 230VAC |
DC adjustment range | 90%~110% rated output voltage |
Current adjustment range | 75%~103% |
Over current protection | 100%~110% constant current limiting, auto-recovery |
Over voltage protection | 110%~155% rated output voltage |
Setup time | 2000ms at full load and 230VAC |
Withstand voltage | I/P-O/P: 3.75kVAC |
Working temperature | -30~+50OC (refer to output derating curve) |
Safety standards | UL1310, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved; TUV EN60950-1 approved for PLC-100 only |
EMC standards | EN55015, EN55022 class B (PLC-45/60/100), EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 |
Connection (Input / Output) | 2+2P screw terminal block |
Dimension (LxWxH)(mm) | 160x 46x 30 |
Packing | 0.2kg ; 70pcs / 15kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesPLC Series
-
Power Rating29.7 Watt
-
Output Voltage9 Volt
-
Rated Current3.3 Ampere
-
Input Voltage90V~264V
-
Standards MetCB,CCC,CE,CSA,EAC,PSE,TUV
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-30°C~50°C
-
Warranty2 Year
-
Length16 cm
-
Width4.6 cm
-
Height3 cm
-
Weight0.2 kg
