Mean Well PSP-600-13.5 Power Supply 600W 13.5V

built-in active PFC, current sharing up to 2400W(3+1)

SKU:

PSP-600-13.5

Please for Pricing

Notify me when it's back in stock

Description

The PSP-600 is a 600W Mean Well power converter (input range: 88~264VAC).

Key Features

✓ Input voltage range: 88~264VAC
✓ DC output voltage adjustable ±10%
✓ 3KVAC reinforced I/O isolation
✓ Protections: Overload / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: UL62368-1, TUV EN62368-1, CCC GB4943.1 BSMI CNS14336-1 EAC TP TC 004
✓ 3 years warranty

Specifications

Brand

Mean Well
Series

PSP Series
Power Rating

600.75 Watt
Output Voltage

13.5 Volt
Rated Current

44.5 Ampere
Input Voltage

88V~264V
Standards Met

BSMI,CB,CE,EAC,UL
Operation Mode

Constant Voltage
Operating Temperature

-20°C~60°C
Warranty

3 Year
Length

17 cm
Width

12 cm
Height

9.3 cm
Weight

1.9 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the PSP-600-13.5 for a 13.5V communications or control cabinet?

Yes, if the cabinet equipment is designed for a constant 13.5V DC source. This model provides 600.75W at 13.5V with up to 44.5A, which suits higher-current 13.5V industrial or communications loads that stay within those limits.

Is the PSP-600-13.5 suitable for 13.5V embedded or industrial electronics that need high current?

It can be, provided the system requires regulated 13.5V DC and the total load does not exceed 44.5A or 600.75W. Because it is a constant voltage power supply, it is intended for equipment that expects a fixed 13.5V output.

Can this power supply support a 13.5V DC distribution load in automation equipment?

Yes, for automation or control equipment built around 13.5V DC input. Its 600.75W output and 44.5A capacity make it appropriate for larger 13.5V loads where a constant voltage supply is required.

Is the PSP-600-13.5 rated for outdoor or harsh-environment use?

The listed specs show an operating temperature range of -20°C to +60°C, but they do not list an IP rating. That means temperature capability is defined, but outdoor or washdown suitability should not be assumed from the provided specs alone.

How does the PSP-600-13.5 compare with other PSP series models?

Within the listed siblings, PSP-1000-24 is 1000W, 24V, 37.6A; PSP-1500-24 is 1500W, 24V, 56.4A; PSP-500-13.5 is 499.5W, 13.5V, 37A; PSP-500-15 is 495W, 15V, 33A; PSP-500-24 is 499.2W, 24V, 20.8A; PSP-500-27 is 499.5W, 27V, 18.5A. Other 600 series siblings are PSP-600-12 at 600W, 12V, 50A; PSP-600-15 at 600W, 15V, 40A; PSP-600-24 at 600W, 24V, 25A; PSP-600-27 at 599.4W, 27V, 22.2A; PSP-600-48 at 600W, 48V, 12.5A; and PSP-600-5 at 400W, 5V, 80A.

Model	Power	Voltage	Current
Mean Well PSP-600-5 Power Supply 400W 5V	400W	5V	80A	View
Mean Well PSP-600-48 Power Supply 600W 48V	600W	48V	12.5A	View
Mean Well PSP-600-27 Power Supply 600W 27V	599.4W	27V	22.2A	View
Mean Well PSP-600-24 Power Supply 600W 24V	600W	24V	25A	View
Mean Well PSP-600-15 Power Supply 600W 15V	600W	15V	40A	View
Mean Well PSP-600-12 Power Supply 600W 12V	600W	12V	50A	View
