Mean Well PSP-600-27 Power Supply 600W 27V

built-in active PFC, current sharing up to 2400W(3+1)

SKU:

PSP-600-27

Please for Pricing

Notify me when it's back in stock

Description

The PSP-600 is a 600W Mean Well power converter (input range: 88~264VAC).

Key Features

✓ Input voltage range: 88~264VAC
✓ DC output voltage adjustable ±10%
✓ 3KVAC reinforced I/O isolation
✓ Protections: Overload / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: UL62368-1, TUV EN62368-1, CCC GB4943.1 BSMI CNS14336-1 EAC TP TC 004
✓ 3 years warranty

Specifications

Brand

Mean Well
Series

PSP Series
Power Rating

599.4 Watt
Output Voltage

27 Volt
Rated Current

22.2 Ampere
Input Voltage

88V~264V
Standards Met

BSMI,CB,CE,EAC,UL
Operation Mode

Constant Voltage
Operating Temperature

-20°C~60°C
Warranty

3 Year
Length

17 cm
Width

12 cm
Height

9.3 cm
Weight

1.9 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the PSP-600-27 for equipment that specifically requires 27V DC?

Yes, if the equipment is designed for a constant 27V DC input. This model delivers 599.4W at 27V with up to 22.2A, so it fits 27V industrial or embedded loads within those ratings.

Is the PSP-600-27 suitable for 27V control, communications, or monitoring systems?

It can be used where the system calls for regulated 27V DC and the load remains at or below 22.2A and 599.4W. Because it is a constant voltage unit, it is intended for electronics that specify a fixed 27V supply.

Can this model support a higher-power 27V DC load in automation hardware?

Yes, for automation hardware built around 27V DC and staying within 599.4W total output. The series features also list current sharing up to 2400W (3+1) for larger-capacity applications using multiple units.

What kind of environment is the PSP-600-27 rated for?

The listed operating temperature range is -20°C to +60°C. No IP rating is provided in the supplied specs, so environmental sealing or outdoor suitability is not established by this data set.

What are the sibling options around the PSP-600-27?

The listed siblings are PSP-1000-24 at 1000W, 24V, 37.6A; PSP-1500-24 at 1500W, 24V, 56.4A; PSP-500-13.5 at 499.5W, 13.5V, 37A; PSP-500-15 at 495W, 15V, 33A; PSP-500-24 at 499.2W, 24V, 20.8A; and PSP-500-27 at 499.5W, 27V, 18.5A. The other 600 series models are PSP-600-12 at 600W, 12V, 50A; PSP-600-13.5 at 600.75W, 13.5V, 44.5A; PSP-600-15 at 600W, 15V, 40A; PSP-600-24 at 600W, 24V, 25A; PSP-600-48 at 600W, 48V, 12.5A; and PSP-600-5 at 400W, 5V, 80A.

Model	Power	Voltage	Current
Mean Well PSP-600-5 Power Supply 400W 5V	400W	5V	80A	View
Mean Well PSP-600-48 Power Supply 600W 48V	600W	48V	12.5A	View
Mean Well PSP-600-24 Power Supply 600W 24V	600W	24V	25A	View
Mean Well PSP-600-15 Power Supply 600W 15V	600W	15V	40A	View
Mean Well PSP-600-13.5 Power Supply 600W 13.5V	600.75W	13.5V	44.5A	View
Mean Well PSP-600-12 Power Supply 600W 12V	600W	12V	50A	View
