Mean Well

Mean Well PWM-60-24KN AC-DC Single output LED driver Constant Voltage (CV) 2.5A

constant voltage PWM style outputbuilt-in active PFC functionstandby power consuption<0.5Wno need KNX-DALI gateway
SKU PWM-60-24KN
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
In stock
|

Overview

PWM-60-24KN is the 24V output model of this series: rated current 2.5A, rated power 60W, typical efficiency 89%.

PWM KN series is a 60W AC/DC LED driver featuring the constant voltage mode with PWM style output, which is able to maintain the colour temperature and the brightness homogeneity when driving all kinds of LED strips and constant voltage LED bulbs.The built-in KNX interface is to avoid using the complicated KNX-DALI gateway. PWM KN operates from 90~305VAC and offers two models with output voltage 12V and 24V.Thanks to the high efficiency up to 89%, with the fanless design, the entire series is able to operate for -35℃ ~ +90℃ case temperature under free air convection. The minimal dimming level low to 0.01% is suitable for low light level applications e.g. cinema. The output frequency is changeable up to 4KHz compliant IEEE1789-2015 no risk requirement and EU Ecodesign stroboscopic visibility measure (SVM) requirement providing a great solution for health concern due to light flickering.

Features

  • Constant Voltage PWM style output with user changeable frequency up to 4KHz design compliant IEEE1789-2015 and EU Ecodesign SVM requirement
  • Min. dimming level 0.01%
  • Plastic housing with class II design
  • Standby power consumption<0.5W
  • Integrated KNX control protocol
  • No need KNX-DALI gateway
  • Typical lifetime>50000 hours
  • 5 years warranty

Specifications

PWM-60-24KNSpecifications from the official datasheet (2026-02-04 edition)

OUTPUT

DC VOLTAGE
24V
RATED CURRENT
2.5A
RATED POWER
60W
DIMMING RANGE
0 ~ 100%
PWM FREQUENCY (Typ.)
200~4000Hz user changable via ETS
SETUP, RISE TIMENote.2
500ms, 80ms/ 115AC or 230VAC
HOLD UP TIME (Typ.)
16ms/115VAC or 230VAC

INPUT

VOLTAGE RANGENote.3
90 ~ 305VAC 127 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE
47 ~ 63Hz
POWER FACTOR (Typ.)
PF>0.97/115VAC, PF>0.95/230VAC, PF>0.92/277VAC @ full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION
THD< 20%(@load≧60%/115VAC, 230VAC; @load≧75%/277VAC) (Please refer to “TOTAL HARMONIC DISTORTION” section)
EFFICIENCY (Typ.)
89%
AC CURRENT (Typ.)
0.8A / 115VAC 0.4A / 230VAC 0.32A / 277VAC
INRUSH CURRENT (Typ.)
COLD START 50A(twidth=350μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. NO. of PSUs on 16A CIRCUIT BREAKER
9 units (circuit breaker of type B) / 16 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT
<0.25mA / 277VAC
STANDY POWER CONSUMPTION
<0.5W

PROTECTION

OVERLOAD
108 ~ 130% rated output power Hiccup mode, recovers automatically after fault condition is removed
SHORT CIRCUIT
Shut down o/p voltage, re-power on to recover
OVER VOLTAGE
28 ~ 34V Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE
Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.
Tcase=-35 ~ +85℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
MAX. CASE TEMP.
Tcase=+85℃
WORKING HUMIDITY
20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY
-35 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT
±0.03%/℃ (0 ~ 50℃)
VIBRATION
10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDSNote.5
ENEC BS EN/EN61347-1, BS EN/EN61347-2-13, BS EN/EN62384 independent, GB/T19510.1,GB/T19510.213, BIS IS 15885(Part2/Sec13)(for 12/24 KN), EAC TP TC 004 approved
KNX STANDARDS
Certified protocol
WITHSTAND VOLTAGE
I/P-O/P:3.75KVAC
ISOLATION RESISTANCE
I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSIONNote.6
Compliance to BS EN/EN55015, BS EN/EN61000-3-2 Class C (@load≧60%) ; BS EN/EN61000-3-3,GB/T 17743, GB17625.1;EAC TP TC 020
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547, light industry level (surge immunity Line-Line 2KV),EAC TP TC 020

OTHERS

MTBF
2135.2K hrs min. Telcordia SR-332 (Bellcore) ; 247.7K hrs min. MIL-HDBK-217F (25℃)
DIMENSION
150*53*35mm (L*W*H)
PACKING
0.45Kg;30pcs/16.0Kg/1.0CUFT
Test conditions and notes8
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25℃ of ambient temperature.
  2. 2. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
  3. 3. Length of set up time is measured at first cold start. Turning ON/OFF the driver may lead to increase of the set up time.
  4. 4. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
  5. 5. This series meets the typical life expectancy of >50,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 75℃ or less.
  6. 6. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com
  7. 7. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
  8. 8. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf

Technical drawings

PWM-60-24KN AC/L(Brown)
AC/L(Brown)
PWM-60-24KN Illustration (page 3)
Illustration (page 3)
PWM-60-24KN OUTPUT LOAD vs TEMPERATURE
OUTPUT LOAD vs TEMPERATURE
PWM-60-24KN STATIC CHARACTERISTIC
STATIC CHARACTERISTIC
PWM-60-24KN TOTAL HARMONIC DISTORTION
TOTAL HARMONIC DISTORTION
PWM-60-24KN LIFE TIME
LIFE TIME
PWM-60-24KN Block Diagram
Block Diagram
PWM-60-24KN Mechanical Specification
Mechanical Specification
PWM-60-24KN Mechanical view of by request
Mechanical view of by request
PWM-60-24KN Recommend Mounting Direction
Recommend Mounting Direction

Typical applications

  • LED strip lighting
  • Indoor LED lighting
  • LED decorative lighting
  • LED architecture lighting

Downloads

FAQ

Can I use the PWM-60-24KN in a KNX smart home lighting system?

Yes. The PWM-60-24KN features a built-in KNX interface, allowing it to be directly controlled over a KNX bus for dimming and switching without requiring a separate KNX-DALI gateway. This simplifies wiring and reduces system cost in KNX-based residential or commercial installations.

Is the PWM-60-24KN suitable for outdoor LED strip installations controlled via KNX?

Yes. The IP67 waterproof rating means the driver can be mounted in outdoor enclosures exposed to rain and wet conditions, while the -40°C to +90°C operating range handles both cold winter and hot summer environments. KNX dimming control is maintained over the bus regardless of location.

What is the advantage of the PWM-60-24KN over a standard driver plus KNX-DALI gateway?

The PWM-60-24KN integrates the KNX interface directly into the driver, eliminating the need for a separate KNX-DALI gateway in the installation. This reduces hardware cost, cabinet space, and potential failure points. The standby power consumption is also rated below 0.5W.

How much 24V LED strip can the PWM-60-24KN drive?

The PWM-60-24KN delivers up to 60W at 24V and 2.5A. For a 15 W/m strip, that allows approximately 4 meters; for a 10 W/m strip, up to 6 meters. Always check your strip's rated power per meter, and derate the driver to 80% (48W effective) for continuous operation.

Can the PWM-60-24KN be used for zone-controlled hotel corridor lighting on a KNX network?

Yes. This driver is well-suited for zone lighting in hospitality environments where KNX is the building automation backbone. Each driver can be individually addressed on the KNX bus, enabling scene control and dimming per zone without additional gateways.

Does the active PFC function on the PWM-60-24KN matter for large installations?

Yes. The built-in active power factor correction (PFC) reduces reactive power on the supply line, which is particularly valuable when many drivers are running in parallel in commercial buildings. It helps meet power quality requirements and reduces electrical infrastructure loading.
