Mean Well XTR-240-48PI Three Phase Din Rail Power Supply 240W 48V -...
Please Login for Pricing
Description
Description
TheXTR-240series is a compact and high-performance 240W AC/DC power supply designed for industrial environments. Its ultra-slim design and robust construction make it ideal for space-constrained installations, while delivering reliable power for industrial control systems, semiconductor fabrication, and factory automation. It operates with a wide input range and offers high efficiency, ensuring energy savings and reduced carbon footprint.
Key Features:
Specifications
Specifications
-
BrandMean Well
-
SeriesMean Well XTR Series
-
Power Rating240 Watt
-
Output Voltage48 Volt
-
Rated Current5 Ampere
-
Input Voltage320V~600V
-
Standards MetCB,CCC,CE,EAC,EN,KC
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length12.5 cm
-
Width4.8 cm
-
Height12.52 cm
-
Weight0.8 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What are the main output specifications of the Mean Well XTR-240-48PI?
The XTR-240-48PI is a 240W AC/DC DIN rail power supply with a 48V DC output. It is rated for 5A output current, making it suitable for industrial systems that require a regulated 48V supply.
What applications is the XTR-240-48PI commonly used for?
This model is designed for industrial environments where compact DIN rail power is needed. Typical uses include industrial control systems, semiconductor fabrication equipment, and factory automation applications.
What operating temperature range does the XTR-240-48PI support?
The XTR-240-48PI is specified for operation from -40°C to 85°C. That wide temperature range makes it suitable for demanding industrial environments where ambient conditions can vary significantly.
How much does the Mean Well XTR-240-48PI weigh?
The XTR-240-48PI weighs 0.8 kg. Its compact DIN rail format and relatively low weight are useful for space-constrained industrial panels and equipment builds.
Is the XTR-240-48PI intended for three-phase AC/DC power supply applications?
Yes. The product name identifies the XTR-240-48PI as a three-phase DIN rail AC/DC power supply. It is intended for industrial power systems that need a 240W, 48V DIN rail supply.
What warranty period applies to the XTR-240-48PI?
The XTR-240-48PI has a 5-year warranty period. This is useful for buyers planning industrial systems where long service life and supplier support are important purchasing factors.
When would this 48V 240W DIN rail power supply be a good choice?
The XTR-240-48PI is a good fit when a system requires 48V DC output, up to 5A current, and 240W power capacity in a DIN rail form factor. It is especially relevant for industrial control, automation, and other applications where compact size and wide temperature operation are important.
