Can I use the SFTN01L-12 to create a 12V rail for a low-power PLC or automation interface board from a 4.5~5.5V source?

Yes, this converter is intended for constant-voltage 12V output when the available input is 4.5~5.5V. Because it is rated at 1W, it is best matched to low-power PLC, automation, or control interface sections rather than larger 12V loads.

Is this a fit for powering a small 12V instrumentation or monitoring circuit?

It can fit that use case when the circuit needs a regulated 12V output and the source falls within the 4.5~5.5V input range. The 1W rating and 0.08A output current place it in the low-power instrumentation category.

Would the SFTN01L-12 work in a space-constrained embedded or industrial device?

Its dimensions are 15.24 × 10.9 × 7.1 mm, so it is well suited to compact embedded assemblies and dense control hardware. The constant-voltage 12V output also makes it relevant for small industrial electronics that need a dedicated 12V rail.

Can this converter be used in equipment that sees very low or very high ambient temperatures?

The specified operating temperature range is -40°C to +90°C, which covers cold and hot equipment environments. The product data does not list an IP rating, so temperature capability is defined but exposure protection is not.

How is the SFTN01L-12 different from the other SFTN01L output options?

The sibling models mainly differ by output voltage and output current while staying in the same 1W family. The SFTN01L-05 is 5V and 200A, the SFTN01L-09 is 9V and 111A, the SFTN01L-12 is 12V and 0.08A, and the SFTN01L-15 is 15V and 0.07A.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SFTN01L-12 DC-DC Converter - 1W - 4.5~5.5V in 12V out 84mA

SKU:

SFTN01L-12

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The SFTN01L is a 1W Mean Well power converter (input range: 4.5~5.5Vdc).

Key Features

✓ Input voltage range: 4.5~5.5Vdc
✓ 3KVDC reinforced I/O isolation
✓ Protections: Short circuit
✓ Safety approvals: UL62368-1(Except for 9V output models), EAC TP TC 004
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SFTN01N-15 DC-DC Converter - 1W - 21.6~26.4V in 15V out 67mA	1W	15V	0.06A	Indoor	View
Mean Well SFTN01N-12 DC-DC Converter - 1W - 21.6~26.4V in 12V out 84mA	1W	12V	0.08A	Indoor	View
Mean Well SFTN01N-09 DC-DC Converter - 1W - 21.6~26.4V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01N-05 DC-DC Converter - 1W - 21.6~26.4V in 5V out 200mA	1W	5V	0.2A	Indoor	View
Mean Well SFTN01M-15 DC-DC Converter - 1W - 10.8~13.2V in 15V out 67mA	1W	15V	0.06A	Indoor	View
Mean Well SFTN01M-12 DC-DC Converter - 1W - 10.8~13.2V in 12V out 84mA	1W	12V	0.08A	Indoor	View
Mean Well SFTN01M-09 DC-DC Converter - 1W - 10.8~13.2V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01M-05 DC-DC Converter - 1W - 10.8~13.2V in 5V out 200mA	1W	5V	0.2A	Indoor	View
Mean Well SFTN01L-15 DC-DC Converter - 1W - 4.5~5.5V in 15V out 67mA	1W	15V	0.06A	Indoor	View
Mean Well SFTN01L-09 DC-DC Converter - 1W - 4.5~5.5V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01L-05 DC-DC Converter - 1W - 4.5~5.5V in 5V out 200mA	1W	5V	0.2A	Indoor	View
