Mean Well SFTN01N-15 DC-DC Converter - 1W - 21.6~26.4V in 15V out 67mA
Log in to see priceThe SFTN01N is a 1W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1(Except for 9V output models), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSFTN Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage21.6V~26.4V
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.52 cm
-
Width1.09 cm
-
Height0.71 cm
-
Weight0 kg
::specification::
Frequently Asked Questions
Can I use the SFTN01N-15 in a 24V industrial control panel that needs a small 15V rail?
Yes, this converter is intended for applications with a 21-26VAC input and provides a constant 15V output. Its 1W power rating and 0.07A output current make it better suited to low-power control, sensing, or interface circuits rather than larger loads.
Is this DC-DC converter suitable for embedded or automation modules that only need a very low 15V load?
It can fit low-power embedded or automation use cases where the required output is 15V and the load stays within 1W and 0.07A. The constant voltage output is appropriate when the downstream device expects a regulated 15V supply.
Can this model power a small isolated 15V section inside industrial electronics?
It is designed for small-power conversion with a 21-26VAC input and a 15V constant voltage output. With only 1W available, it is a fit for light-duty electronics sections and not for equipment that needs more than 0.07A.
Is the SFTN01N-15 appropriate for indoor or outdoor equipment?
The listed specs include an operating temperature range of -40°C to +90°C, which supports use across a wide temperature span. However, no IP rating or enclosure protection level is provided here, so outdoor suitability is not specified by these specs alone.
How does the SFTN01N-15 compare with the other SFTN01N models?
Within the SFTN01N series, all listed models are 1W converters, but they differ in output. The SFTN01N-05 is 5V at 200A, the SFTN01N-09 is 9V at 111A, the SFTN01N-12 is 12V at 0.08A, and this SFTN01N-15 is 15V at 0.07A.
