Can I use the SFTN01N-12 for a small 12V industrial control or signal circuit from a 24V-class source?

It is designed for low-power conversion from a 21-26VAC input to a constant 12V output. With a 1W rating and 0.08A output current, it is appropriate for small auxiliary control or signal functions rather than higher-current 12V loads.

Is the SFTN01N-12 suitable for embedded 12V electronics in compact equipment?

Yes, its compact size of 15.24 x 10.9 x 7.1 mm and weight of 0.0012 kg help in space-constrained embedded designs. The 12V constant-voltage output at 1W makes it best suited to very small onboard 12V sections.

Can this converter power a light-duty 12V monitoring or interface module?

It can fit that role when the module operates within 12V, 0.08A, and 1W. That makes it more suitable for light-duty monitoring, signaling, or interface functions than for larger 12V automation hardware.

Is the SFTN01N-12 meant for exposed outdoor environments?

The operating temperature range is -40°C to +90°C, so the temperature capability is broad. However, no IP rating is listed, so the provided specs do not define moisture or dust protection for outdoor exposure.

How does the SFTN01N-12 compare to the other models in the same series?

The listed SFTN01N siblings are SFTN01N-05 at 1W, 5V, 200A; SFTN01N-09 at 1W, 9V, 111A; and SFTN01N-15 at 1W, 15V, 0.07A. The SFTN01N-12 version is the 1W model with 12V output and 0.08A output current.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SFTN01N-12 DC-DC Converter - 1W - 21.6~26.4V in 12V out 84mA

SKU:

SFTN01N-12

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The SFTN01N is a 1W Mean Well power converter (input range: 4.5~5.5Vdc).

Key Features

✓ Input voltage range: 4.5~5.5Vdc
✓ 3KVDC reinforced I/O isolation
✓ Protections: Short circuit
✓ Safety approvals: UL62368-1(Except for 9V output models), EAC TP TC 004
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SFTN01N-15 DC-DC Converter - 1W - 21.6~26.4V in 15V out 67mA	1W	15V	0.06A	Indoor	View
Mean Well SFTN01N-09 DC-DC Converter - 1W - 21.6~26.4V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01N-05 DC-DC Converter - 1W - 21.6~26.4V in 5V out 200mA	1W	5V	0.2A	Indoor	View
Mean Well SFTN01M-15 DC-DC Converter - 1W - 10.8~13.2V in 15V out 67mA	1W	15V	0.06A	Indoor	View
Mean Well SFTN01M-12 DC-DC Converter - 1W - 10.8~13.2V in 12V out 84mA	1W	12V	0.08A	Indoor	View
Mean Well SFTN01M-09 DC-DC Converter - 1W - 10.8~13.2V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01M-05 DC-DC Converter - 1W - 10.8~13.2V in 5V out 200mA	1W	5V	0.2A	Indoor	View
Mean Well SFTN01L-15 DC-DC Converter - 1W - 4.5~5.5V in 15V out 67mA	1W	15V	0.06A	Indoor	View
Mean Well SFTN01L-12 DC-DC Converter - 1W - 4.5~5.5V in 12V out 84mA	1W	12V	0.08A	Indoor	View
Mean Well SFTN01L-09 DC-DC Converter - 1W - 4.5~5.5V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01L-05 DC-DC Converter - 1W - 4.5~5.5V in 5V out 200mA	1W	5V	0.2A	Indoor	View
