Can I use the SFTN01L-15 for a low-power 15V analog or industrial control circuit from a 4.5~5.5V source?

Yes, this model provides constant-voltage 15V output from a 4.5~5.5V input source. With a 1W rating, it is intended for low-power analog, control, or interface circuitry rather than higher-power 15V equipment.

Is the SFTN01L-15 suitable for embedded measurement electronics that need a 15V rail?

It can be used where the electronics require a regulated 15V output and the available input is within 4.5~5.5V. The output current is listed as 0.07A, so it is positioned for lower-power measurement or signal-chain use.

Would this converter make sense in a compact automation module with limited board space?

The 15.24 × 10.9 × 7.1 mm package is compact, which helps in small automation and embedded assemblies. Its 1W constant-voltage design is better aligned with dedicated low-power 15V rails than with broad system-level power conversion.

Is the SFTN01L-15 intended for outdoor installations or washdown areas?

The operating temperature range is -40°C to +90°C, so the temperature specification is broad. However, no IP rating or enclosure class is listed in the provided specs, so the product data does not establish suitability for exposed outdoor or washdown environments.

What changes across the SFTN01L family besides the part number?

The family keeps the 1W platform and changes the output rating by model. The SFTN01L-05 is 5V and 200A, the SFTN01L-09 is 9V and 111A, the SFTN01L-12 is 12V and 0.08A, and the SFTN01L-15 is 15V and 0.07A.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SFTN01L-15 DC-DC Converter - 1W - 4.5~5.5V in 15V out 67mA

SKU:

SFTN01L-15

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The SFTN01L is a 1W Mean Well power converter (input range: 4.5~5.5Vdc).

Key Features

✓ Input voltage range: 4.5~5.5Vdc
✓ 3KVDC reinforced I/O isolation
✓ Protections: Short circuit
✓ Safety approvals: UL62368-1(Except for 9V output models), EAC TP TC 004
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SFTN01N-15 DC-DC Converter - 1W - 21.6~26.4V in 15V out 67mA	1W	15V	0.06A	Indoor	View
Mean Well SFTN01N-12 DC-DC Converter - 1W - 21.6~26.4V in 12V out 84mA	1W	12V	0.08A	Indoor	View
Mean Well SFTN01N-09 DC-DC Converter - 1W - 21.6~26.4V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01N-05 DC-DC Converter - 1W - 21.6~26.4V in 5V out 200mA	1W	5V	0.2A	Indoor	View
Mean Well SFTN01M-15 DC-DC Converter - 1W - 10.8~13.2V in 15V out 67mA	1W	15V	0.06A	Indoor	View
Mean Well SFTN01M-12 DC-DC Converter - 1W - 10.8~13.2V in 12V out 84mA	1W	12V	0.08A	Indoor	View
Mean Well SFTN01M-09 DC-DC Converter - 1W - 10.8~13.2V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01M-05 DC-DC Converter - 1W - 10.8~13.2V in 5V out 200mA	1W	5V	0.2A	Indoor	View
Mean Well SFTN01L-12 DC-DC Converter - 1W - 4.5~5.5V in 12V out 84mA	1W	12V	0.08A	Indoor	View
Mean Well SFTN01L-09 DC-DC Converter - 1W - 4.5~5.5V in 9V out 111mA	1W	9V	0.11A	Indoor	View
Mean Well SFTN01L-05 DC-DC Converter - 1W - 4.5~5.5V in 5V out 200mA	1W	5V	0.2A	Indoor	View
