Mean Well SFTN01N-05 DC-DC Converter - 1W - 21.6~26.4V in 5V out 200mA
Log in to see priceThe SFTN01N is a 1W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1(Except for 9V output models), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSFTN Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage21.6V~26.4V
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.52 cm
-
Width1.09 cm
-
Height0.71 cm
-
Weight0 kg
::specification::
Frequently Asked Questions
Can I use the SFTN01N-05 to derive 5V power inside a 24V-class industrial system?
It is intended for that kind of low-power conversion, with an input spec of 21-26VAC and a constant 5V output. The converter is rated at 1W, so it is appropriate for small logic, monitoring, or interface sections rather than higher-power 5V loads.
Is the SFTN01N-05 suitable for embedded 5V control electronics in compact equipment?
Yes, the very small 15.24 x 10.9 x 7.1 mm body and 0.0012 kg weight make it useful where space is limited. Its published output is 5V constant voltage at 200A with a 1W rating, so it should be evaluated against the exact load requirement shown in the specs.
Can this converter be used for a small 5V automation interface or sensor section?
It can be considered for a low-power 5V interface or sensor-related section when the system input matches 21-26VAC. The 1W rating makes it a better fit for light auxiliary electronics than for larger automation devices.
Is the SFTN01N-05 rated for outdoor conditions?
The operating temperature range is listed as -40°C to +90°C, which supports use across a broad temperature span. However, no IP rating is shown in the provided specs, so the data does not define outdoor exposure or enclosure protection level.
How does the SFTN01N-05 compare with the other SFTN01N converters?
The listed siblings are SFTN01N-09 at 1W, 9V, 111A; SFTN01N-12 at 1W, 12V, 0.08A; and SFTN01N-15 at 1W, 15V, 0.07A. The SFTN01N-05 version is the 1W, 5V model with a listed output current of 200A.
