What type of product is the Archilight Curion 185 Downlight 12.7W?

The Archilight Curion 185 is a recessed LED downlight for interior lighting applications. It is part of the Curion family and is designed as a compact, high-end luminaire with a Holland-made fitting.

What are the key performance specifications of the Curion 185 family?

This parent model is rated at 12.7W and the listed variant delivers 5500 lumens with a CRI of 82. It also has a 70,000-hour lifetime and is backed by a 7-year warranty.

Is the Archilight Curion 185 downlight dimmable?

Yes, the Curion 185 family is listed as dimmable optional. That means dimming capability is available for this product family, but it is not described here as a standard built-in control method.

What light color and beam angle are available in the listed Curion 185 variant?

The variant shown for this parent model is specified at 4000K with an 80-degree beam angle. No other color temperatures or beam spreads are provided in the data shown here.

Where can the Curion 185 be used, and what is its IP rating?

The Curion 185 is intended for interior use and is rated IP44 under a specific condition. According to the product description, it may be exposed to water splashes only when installed in a closed ceiling, and only on the front side.

What are the dimensions and cut-out size for the Curion 185?

The parent model dimensions are 230 mm by 230 mm with a height of 85 mm, and the listed weight is 1.4 kg. The available child data shows a cut-out size of 185 mm.

1 3

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Archilight

Archilight Curion 185 Downlight 12.7W

SKU:

956903MW6702

Log in to see price Trade pricing & online ordering for account holders

LED Colour

Natural White 4000K

Finish Colour

White

Beam Angle

80 Degree

Product variants

Notify me when it's back in stock

At Archilight we research and provide inventive lighting solutions, which offer as much comfort and ease as possible, all without damaging the environment on a day to day basis. After many years of experience in product development our results show in a range of completely self-developed, high-end luminaires.

Backed up by 7 years warranty, Curion is designed to waste no space and effort, while creating the best lighting experience possible with our proudly Holland made fitting. The colour is truly consistent with MacAdam step 3 SDCM.

IP44 - Only when the product is installed in a closed ceiling it may be exposed to water splashes, and only on its front side.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	CRI	Dimming	Cut-out
Archilight Curion 90 Downlight 16W	16W	82	Optional	90 Millimeter	View
Archilight Curion 75 Series 16W Recessed Downlight	16W	80	Optional	75 Millimeter	View
Archilight 7W Sensor-Equiped Recessed Downlight	7W	80	Optional	75 Millimeter	View
