Archilight

LED Strip Pro High-Density 280LEDs/m 14W/m 24V IP65 CRI>90

SKU:
Z-HD2216-2802465GLE-CW-5
Length
LED Colour
Please for Pricing
|

Description
Plus Series using top quality material, such as Epistar chip, Intermatix phosphor powder, ShinEtsu & Dow Corning glue, Heraeus 99.99% pure golden wire, pure copper etc. • Tiny package of 2216 LED, more appropriate for furniture lighting with demand of high-density performance with CRI 90, IP65 rated

Specifications
  • Brand
    Archilight
  • Series
    ProPlus Ultra High CRI Series
  • Power Rating
    14 Watt
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -10°C~50°C
  • Warranty
    5 Year
  • Width
    1 cm
  • Height
    0.2 cm
  • Weight
    0.2 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What is this archilight high-density LED strip best suited for?

This LED strip is designed for high-density linear lighting where a compact strip profile and high color quality are important. The 2216 LED package, 280 LEDs per meter, CRI greater than 90, and 10 mm strip width make it suitable for furniture lighting and interior linear lighting applications that need a more continuous-looking light output.

Which color temperatures are available for this LED strip model?

This parent model is available in 3000K warm white, 4000K neutral white, and 6000K cool white variants. The main electrical and construction specs remain the same across those variants, including 24V input, 14 W/m power rating, IP65 rating, and 5-year warranty.

Is the driver included with this LED strip?

No, the driver is not included with this product model. It is specified as a 24V LED strip, so the driver or power supply should be selected separately to match the project requirements and control method.

Can this LED strip be dimmed?

Yes, dimming is listed as optional for this product model. Dimming capability depends on the separate driver and control equipment selected for the project, since the driver is not included with the strip.

What does the IP65 rating mean for this LED strip?

The product is IP65 rated, which indicates added protection compared with a non-rated indoor strip. It is appropriate for environments where an IP65 LED strip is required, but the listed data does not describe it as submersible.

What are the key specifications for this parent LED strip model?

The strip is rated at 14 W/m with 24V power input and uses a high-density 280 LEDs per meter layout. It has a 10 mm width, 2 mm height, CRI greater than 90, IP65 rating, and a 5-year warranty.

How bright are the available variants?

The listed child variants for 3000K, 4000K, and 6000K each show 7000 lm brightness. No brightness difference is provided between the color-temperature options in the supplied product data.

{ "id":8442914537771, "variants" :[{ "context":"default", "variant_id": 45713389224235, "sku":"Z-HD2216-2802465GLE-CW-5", "inventory_qty" : 7, "customer" :false, "custom_html" :"\u003ca class=\"text-current logged-out-price logged-out\" href=\"https:\/\/wellforces.co.nz\/customer_authentication\/redirect?locale=en\u0026region_country=NZ\"\u003e\n \u003cspan \u003ePlease \u003c\/span\u003e \u003cspan class=\"login-text\"\u003eLogin\u003c\/span\u003e \u003cspan\u003e for Pricing\u003c\/span\u003e\n \u003c\/a\u003e", "volume_html" :"\u003cvolume-pricing class=\"parent-display inside_product_form\" id=\"volume-pricing-main\" \u003e\u003c\/volume-pricing\u003e" }, { "context":"default", "variant_id": 45713389486379, "sku":"Z-HD2216-2802465GLE-NW-5", "inventory_qty" : 8, "customer" :false, "custom_html" :"\u003ca class=\"text-current logged-out-price logged-out\" href=\"https:\/\/wellforces.co.nz\/customer_authentication\/redirect?locale=en\u0026region_country=NZ\"\u003e\n \u003cspan \u003ePlease \u003c\/span\u003e \u003cspan class=\"login-text\"\u003eLogin\u003c\/span\u003e \u003cspan\u003e for Pricing\u003c\/span\u003e\n \u003c\/a\u003e", "volume_html" :"\u003cvolume-pricing class=\"parent-display inside_product_form\" id=\"volume-pricing-main\" \u003e\u003c\/volume-pricing\u003e" }, { "context":"default", "variant_id": 45713389682987, "sku":"Z-HD2216-2802465GLE-WW-5", "inventory_qty" : 0, "customer" :false, "custom_html" :"\u003ca class=\"text-current logged-out-price logged-out\" href=\"https:\/\/wellforces.co.nz\/customer_authentication\/redirect?locale=en\u0026region_country=NZ\"\u003e\n \u003cspan \u003ePlease \u003c\/span\u003e \u003cspan class=\"login-text\"\u003eLogin\u003c\/span\u003e \u003cspan\u003e for Pricing\u003c\/span\u003e\n \u003c\/a\u003e", "volume_html" :"\u003cvolume-pricing class=\"parent-display inside_product_form\" id=\"volume-pricing-main\" \u003e\u003c\/volume-pricing\u003e" } ] }
LED Strip Pro High-Density 280LEDs/m 14W/m 24V IP65 CRI>90
Archilight

LED Strip Pro High-Density 280LEDs/m 14W/m 24V IP65 CRI>90

Please for Pricing
Plus Series using top quality material, such as Epistar chip, Intermatix phosphor powder, ShinEtsu & Dow Corning glue, Heraeus 99.99% pure golden wire, pure copper etc. • Tiny package of 2216 LED, more appropriate for furniture lighting with demand of high-density performance with CRI 90, IP65 rated

Length

  • 500 Centimeter

LED Colour

  • Cool White 6000K
  • Natural White 4000K
  • Warm White 3000K
